Creality Pika 3D Scanner

Price: 711.70 €

Products ID:	177754
Manufactured by:	Creality
Availablity:	Ready to Order
Delivery Time	5-10 business days
EAN:	6977905749737

Delivery options to:

Choose country

The Creality Pika is a compact handheld 3D scanner featuring 7 parallel blue laser lines and NIR structured light for digitizing both fine details and large objects.

Key Features

Dual scanning modes: blue laser for fine contours and NIR structured light for large objects
High accuracy of up to 0.03 mm in laser mode and 3D resolution ranging from 0.1 to 2 mm
Fast scanning speeds reaching up to 110 fps with a PC and up to 40 fps with a smartphone
Supported object size range from 10 × 10 × 10 mm to 2000 × 2000 × 2000 mm
3-inch touchscreen, Wi-Fi 6 connectivity, and two replaceable 3350 mAh batteries for portable use
24-bit color capture and the capability to scan black and metallic surfaces without spray
Export to standard 3D formats including STL, OBJ, PLY, and ASC

Manufacturer	Creality
Model	Pika
Scanning technologies	7 parallel blue laser lines / NIR structured light
Accuracy	up to 0.03 mm (blue laser) / up to 0.1 mm (NIR)
3D resolution	0.1–2 mm (blue laser) / 0.15–2 mm (NIR)
Scanning speed with a computer	up to 110 fps (laser) / up to 30 fps (NIR)
Scanning speed with a smartphone	up to 40 fps (laser) / up to 20 fps (NIR)
Minimum scan volume	10 × 10 × 10 mm (laser) / 150 × 150 × 150 mm (NIR)
Single-capture area – laser	101 × 107 mm at 160 mm / 344 × 268 mm at 400 mm
Single-capture area – NIR	144 × 134 mm at 200 mm / 764 × 670 mm at 1000 mm
Operating distance	160–400 mm (laser) / 140–1000 mm (NIR)
Color mapping	yes
Color	24-bit
Alignment modes – laser	markers / global markers / no markers
Alignment modes – NIR	geometry / texture
Outdoor scanning	up to 110,000 lx (laser) / up to 80,000 lx with filter (NIR)
Additional lighting	4 blue/white LEDs + 4 infrared LEDs
Laser safety	Class I
NIR filter	Yes, for NIR mode
Processor	8-core, 2.0 GHz
Display	3-inch touchscreen
Wireless connectivity	Wi-Fi 6
Interface	USB Type-C / USB 3.0
Input power	5 V / 3 A
Supported platforms	Android, iOS, Windows, macOS
Wired connection with iOS	Not supported
Export formats	STL / OBJ / PLY / ASC
Dimensions	100 × 60 × 35 mm
Weight	260 g with battery
Operating temperature	-10°C to 40°C
Operating humidity	10–90% RH

What items are included in the Creality Pika package?

The package includes the Creality Pika 3D scanner, tripod, glass calibration plate, 2 m USB 3.0 Type-C cable, two 3350 mAh batteries, D6 mm reflective markers (10 pcs), D3 mm reflective markers (10 pcs), 6 marker towers, 2 NIR filters, rotating table, lanyard, cleaning cloth, and documentation.

Which export file formats are supported?

CrealityScan software allows exporting digitized 3D models in STL, OBJ, PLY, and ASC formats.

Can the scanner be used wirelessly with smartphones?

Yes, the Creality Pika supports Wi-Fi 6 wireless connections with Android and iOS devices, as well as Windows and macOS computers.
