Revopoint MetroX Pro Advanced 3D Scanner
Price: 1290.80 €
| Products ID: | 176589 |
|---|---|
| Manufactured by: | Revopoint |
| Availablity: | Ready to Order |
| Delivery Time | 5-10 business days |
| EAN: | 6975577881762 |
Delivery options to:
Choose countryThe Revopoint MetroX Pro Advanced is a 3D scanner combining multi-line laser and full-field structured light technologies for precise mapping in engineering and design.
Key Features
- Multi-line laser and full-field structured light scanning modes
- Captures objects sized from 10 × 10 × 10 mm up to 1 × 1 × 1 m
- Scanning speeds up to 7,000,000 points per second
- Working distance of 200–400 mm with a 43 × 33° field of view
- Supports PLY, OBJ, STL, ASC, 3MF, GLTF, and FBX file formats
- Compatible with Windows 10/11 (64-bit) and macOS 11.0 or later
| Manufacturer | Revopoint |
|---|---|
| Model | MetroX Pro Advanced |
| Scanning technology | Multi-line laser and full-field structured light |
| 3D light source | 30 blue cross-line lasers, 15 parallel laser lines, 62 structured light lines |
| Auxiliary lighting | 12 blue LEDs |
| Minimum scanning volume | 10 × 10 × 10 mm |
| Maximum scanning volume | 1 × 1 × 1 m |
| Working distance | 200 ~ 400 mm |
| Field of view | 43 × 33° |
| Point-to-point distance | 0.05 mm |
| Volumetric accuracy | 0.02 mm + 0.04 mm × L (m) |
| Scanning speed | Up to 2,000,000 pts/s (laser) / 7,000,000 pts/s (structured light) |
| RGB camera resolution | 2 MP |
| Tracking methods | Feature, Marker, Global Marker |
| Processor | 4-core ARM, 2.0 GHz |
| Output file formats | PLY, OBJ, STL, ASC, 3MF, GLTF, FBX |
| Connector type | USB Type-C |
| Power supply | DC 12V, 3A |
| Dimensions | 209 × 88 × 44 mm |
| Weight | 508 g |
What operating systems are supported by the Revopoint MetroX Pro Advanced?
The scanner is compatible with Windows 10/11 (64-bit) and macOS 11.0 or later using Revo Metro software.
What object sizes can the MetroX Pro Advanced scan?
The device handles objects ranging in volume from 10 × 10 × 10 mm up to 1 × 1 × 1 m.
What is included in the Advanced package?
The package includes the scanner, tripod, USB-C cable, power adapter, test model, rotating stand, wrist strap, carrying case, calibration plate, manual, 500 markers (6 mm), and an additional set of magnetic round, dome, pyramid, and strip markers.
