Revopoint MetroX Pro Standard 3D Scanner

Revopoint MetroX Pro Standard 3D Scanner — image 3

Revopoint MetroX Pro Standard 3D Scanner — image 4

Price: 1121.00 €

Products ID:	176590
Manufactured by:	Revopoint
Availablity:	Ready to Order
Delivery Time	5-10 business days
EAN:	6975577881755

Delivery options to:

Choose country

Revopoint MetroX Pro Standard 3D Scanner

The Revopoint MetroX Pro Standard is a versatile 3D scanner combining multi-line laser and structured light technologies for high-precision object digitizing.

Key Features

Single-frame precision up to 0.01 mm and accuracy up to 0.02 mm
Scanning speeds up to 7,000,000 points/s in full-field mode
Scans objects from 10 × 10 × 10 mm up to 1 × 1 × 1 m
Supports handheld and tripod-mounted stationary scanning
Compatible with Windows 10/11 (64-bit) and macOS 11.0 or later
Exports 3D print ready files in PLY, OBJ, STL, ASC, 3MF, GLTF, and FBX formats

Manufacturer	Revopoint
Model	MetroX Pro Standard
Scanning Technology	Multi-line laser and full-field structured light
Single-Frame Precision (Max.)	0.01 mm
Single-Frame Accuracy (Max.)	0.02 mm
Volumetric Accuracy	0.02 mm + 0.04 mm × L (m)
Point Distance (Min.)	0.05 mm
Working Distance	200 ~ 400 mm
Scanning Volume	10 × 10 × 10 mm to 1 × 1 × 1 m
Scanning Speed (Max.)	7,000,000 points/s (full-field) / 2,000,000 points/s (laser)
RGB Camera Resolution	2 MP
3D Light Source	30 blue cross-line lasers, 15 blue parallel line lasers, 62 blue structured light lines
Auxiliary Lighting	12 blue LEDs
Processor	4-core ARM, 2.0 GHz
Output Formats	PLY, OBJ, STL, ASC, 3MF, GLTF, FBX
Connection	USB Type-C to Type-C
Power Supply	DC 12V, 3A
Dimensions	209 × 88 × 44 mm
Weight	508 g

What is the accuracy and precision of the Revopoint MetroX Pro?

It provides a maximum single-frame precision of up to 0.01 mm and a single-frame accuracy of up to 0.02 mm.

What file formats can the scanner export?

The scanner supports exporting models in PLY, OBJ, STL, ASC, 3MF, GLTF, and FBX formats.

What is included in the standard package?

The box includes the scanner, tripod, USB-C to USB-C cable, power adapter, test model, 500 markers (6 mm), rotating stand, wrist strap, carrying case, calibration plate, and user manual.
