3D Scanner Creality Sermoon S1

3D Scanner Creality Sermoon S1 — image 3

3D Scanner Creality Sermoon S1 — image 4

3D Scanner Creality Sermoon S1 — image 5

Price: 2453.10 €

Products ID:	175611
Manufactured by:	Creality
Availablity:	Ready to Order
Delivery Time	5-10 business days
EAN:	6977905741946

Delivery options to:

Choose country

The Creality Sermoon S1 is a professional 3D scanner combining blue laser lines and NIR structured light for versatile digitizing of both fine details and large objects.

Key Features

Multi-Light system with single line, 7 parallel lines, 34 cross lines, and four-lens NIR structured light
Scanning accuracy up to 0.02 mm and volumetric accuracy of 0.02 mm + 0.08 mm/m
Data acquisition rate up to 1,428,000 points per second and speeds up to 90 fps
Scans objects ranging from 5 mm to 4000 mm in size
Full-color capture and built-in temperature compensation for stable measurements
CrealityScan 4.0 software with AI-assisted features and GPU acceleration

Manufacturer	Creality
Model	Sermoon S1
Accuracy	Up to 0.02 mm
Volumetric accuracy	0.02 mm + 0.08 mm/m
3D resolution	0.05-2 mm
Frame rate	Up to 90 fps
Data acquisition speed	Up to 1,428,000 points/s
Object size range	5 mm – 4000 mm
Minimum scan volume	5 mm x 5 mm x 5 mm
Working distance	150 mm – 600 mm
Dimensions	225 mm × 53 mm × 76 mm
Weight	508 g
Operating temperature	-10°C to 40°C
Operating humidity	10-90% RH
Supported operating systems	Windows / macOS

What is the accuracy of the Creality Sermoon S1?

The Sermoon S1 delivers a scanning accuracy of up to 0.02 mm and a volumetric accuracy of 0.02 mm + 0.08 mm/m.

What items are included in the package?

The package includes the scanner, USB 3.0 data cable, power adapter, reflective markers (D6 mm and D3 mm), high-precision glass calibration plate, Type-C adapter, strap, cleaning cloth, waterproof box, and user manual.

Which operating systems are supported?

It natively supports Windows and macOS, and supports Android and iOS when combined with wireless scanning accessories.
