3-Phase PV Smart Meter Growatt TPMCTE100A 100A
217.60 €
Growatt
Products ID: 170520
In supplier warehouse
Available to order: 3 pcs.
Delivery Time 5–10 business days
Delivery options to:
Choose countryThe Growatt TPMCTE100A 100A 3-phase PV smart meter is designed for self-consumption monitoring and grid export limitation in solar energy systems.
Key Features
- Compatible with Growatt PV inverters
- Equipped with an LCD display
- Class 1 measurement accuracy
- RS485 communication with Modbus RTU protocol
- Easy installation on 35mm DIN rail
| Model | TPMCTE100A |
|---|---|
| Number of phases | 3 (3P4W) |
| Rated current | 100A |
| Rated voltage | AC 230/400V |
| L-L voltage range | AC 173 ~ 480V |
| L-N voltage range | AC 100 ~ 289V |
| Frequency | 50/60Hz |
| Accuracy class | Class 1 |
| Interface | RS485 |
| Communication protocol | Modbus RTU |
| Baud rate | 9600 bit/s |
| RS485 cable length | 15m |
| Mounting | 35mm DIN rail |
| Protection rating | IP51 |
| Power consumption | 2W |
| Dimensions | 95.5x72x65 mm |
| Weight | 280g |
| Operating temperature | -25°C to 55°C |
| Operating humidity | 0-90% non-condensing |
| Colour | White |
| Certifications | CE |
| EAN | 6975609727242 |
|---|
Which devices are compatible with this smart meter?
The Growatt TPMCTE100A smart meter is compatible with Growatt PV inverters.
How is the meter installed?
It is designed for mounting on a standard 35mm DIN rail.
