3-Phase PV Smart Meter Growatt TPM-C, 5A-80A
176.40 €
Growatt
Products ID: 170521
In supplier warehouse
Available to order: 1 pcs.
Delivery Time 5–10 business days
Delivery options to:
Choose countryThe Growatt TPM-C 3-phase PV smart meter is designed for grid export limitation and self-consumption monitoring in solar energy systems.
Key Features
- Compatible with Growatt PV inverters
- Equipped with an LCD display
- Class 1 measurement reliability
- RS485 interface with Modbus RTU protocol
- Convenient mounting on DIN rail
| Model | TPM-C |
|---|---|
| Rated voltage | AC 230/400V |
| L-L voltage range | AC 320V ~ 520V |
| Current | 5A |
| Current range | 5A ~ 80A |
| Number of phases | 3 (3P4W) |
| Frequency | 50/60Hz |
| Accuracy class | Class 1 (voltage/current 0.5%, power 1%, frequency 0.2%) |
| Interface | RS485 |
| Baud rate | 9600 bit/s |
| Communication protocol | Modbus RTU |
| Installation | DIN rail |
| Dimensions | 94.5x72x65 mm |
| Safety class | IP51 |
| Operating temperature | -25°C to 55°C |
| EAN | 9990000821143 |
|---|
What is the function of the Growatt TPM-C smart meter?
It is designed for grid export limitation and monitoring self-consumption in solar power setups.
How is the meter installed?
The Growatt TPM-C is designed to be mounted on a standard DIN rail.
