Solar Charge Controller 12V / 24V 30A PWM with LCD Display
Generic
| Products ID: | 121721 |
|---|---|
| Manufactured by: | Generic |
| Availablity: | SOLDOUT! |
| EAN: | 5907621822897 |
Delivery options to:
Choose country
This solar charge controller regulates and transfers energy generated by photovoltaic panels into a battery storage bank. It employs PWM charge control mode to optimize battery charging efficiency.
Clear Monitoring and Simple Operation
A built-in backlit LCD display provides direct, real-time readouts of operational parameters. Tactile physical push-buttons facilitate straightforward adjustment and parameter configuration. Mounting and wiring are straightforward using the diagram provided in the user manual.
Battery Selection and USB Connectivity
The controller features selectable battery chemistries, including lead-acid, gel, and AGM. For external low-voltage power supply, two USB Type-A ports are integrated on the front panel with a shared output of 2.5A.
| Material | ABS plastic |
|---|---|
| Input voltage | 12V / 24V |
| Solar panel voltage | 12V (8-23V) / 24V (16-46V) |
| Maximum charge and discharge current | charge 30A / discharge 10A |
| Maximum load current | 10A |
| Standby power consumption | 10mA |
| Maximum panel power (12V) | 390W |
| Maximum panel power (24V) | 780W |
| Display | Backlit LCD |
| Operating mode | PWM |
| Adjustment controls | Physical buttons |
| Supported battery types | Acid, gel, AGM |
| USB ports | 2x USB Type-A (total current 2.5A) |
| Dimensions (without mount) | 13.35 cm x 7.00 cm x 3.50 cm |
| Packaging | Cardboard box |
Which battery types are compatible with this solar controller?
The controller allows users to select between acid, gel, and AGM battery types.
What is the maximum photovoltaic panel wattage supported?
The maximum solar panel capacity is 390W for 12V systems and 780W for 24V systems.
What are the specifications of the onboard USB ports?
It provides two USB Type-A ports delivering a combined current of up to 2.5A.
