Uni-T UT347A Leeb Hardness Tester with Bluetooth and Thermal Printer

The Uni-T UT347A is a portable Leeb hardness tester designed for field inspections and testing large metal components such as turbines, pressure vessels, and shafts.

Key Features

Supports 6 hardness scales (HL, HB, HRC, HRB, HV, HS) and tensile strength measurement
Built-in thermal printer for on-site report generation
2.8″ TFT color screen and 640×480 camera to document test points
Bluetooth and USB connectivity for PC software and mobile app integration
Internal memory storing up to 900 data sets with 5 impact directions
Powered by a rechargeable 3.7V 2500 mAh Li-Po battery

Manufacturer	Uni-T
Model	UT347A
Hardness scales	HL, HB, HRC, HRB, HV, HS
Strength measurement	σb (tensile strength)
Impact angles	0°, 45°, 90°, 135°, 180°
Measurement modes	statistical, multi-unit, line graph, histogram
Statistics	max / min / avg
Memory	up to 900 data sets
Camera	640×480 (up to 900 BMP images)
Display	2.8″ TFT 320×240
Printing	57 mm thermal paper
Connectivity	Bluetooth (APP), USB, PC software
Over-limit alarms	yes (3-color LED)
Backlight	adjustable
Voice prompts	yes
Power supply	3.7V 2500 mAh Li-Po battery
Charging	DC 5V 2A (USB-C), approx. 2–4 hours
Auto power off	1 / 5 / 10 / 30 min or off
Drop test	1 m
Certifications	CE (pending), UKCA
Materials	steel, alloy steel, stainless steel, cast iron, aluminum, copper, and their alloys

What is included in the Uni-T UT347A package?

The package includes the UT347A hardness tester, a Type D impact probe, a Leeb hardness reference block, a nylon brush, a USB-C cable, a user manual, downloadable guidelines, and 2 rolls of thermal printer paper.

How many measurement results can be stored in the device?

The internal memory can store up to 900 data sets and up to 900 BMP images from the built-in camera.
