FNIRSI 2C23T Portable 3-in-1 Oscilloscope Multimeter Signal Generator
Price: 71.40 €
| Products ID: | 175943 |
|---|---|
| Manufactured by: | Fnirsi |
| Availablity: | Ready to Order |
| Delivery Time | 5-10 business days |
| EAN: | 5907085527307 |
Delivery options to:
Choose country
The FNIRSI 2C23T is a versatile 3-in-1 handheld measurement tool combining a dual-channel oscilloscope, a True RMS multimeter, and a function signal generator in a compact unit with a 2.8" color display and a built-in 3000 mAh battery.
Key Features
- Dual-channel oscilloscope with 10 MHz bandwidth and 50 MS/s sampling rate
- Digital multimeter with True RMS, measuring AC up to 750 V and DC up to 1000 V
- Signal generator offering 7 waveform types with output frequency from 1 Hz to 2 MHz
- 2.8-inch color screen with 320 x 240 pixel resolution
- ABS housing with protective silicone cover and built-in kickstand
- USB Type-C charging port with 5V/1A input
| Brand | FNIRSI |
|---|---|
| Model | 2C23T |
| Screen | 2.8" HD color (320 x 240) |
| Battery | Lithium, 3000 mAh |
| Oscilloscope Channels | Dual channel |
| Analog Bandwidth | 10 MHz |
| Sampling Rate | 50 MS/s |
| Max Voltage (Oscilloscope) | 400 V |
| Input Impedance | 1 MΩ |
| Multimeter Voltage Range | AC up to 750 V, DC up to 1000 V |
| Signal Generator Frequency | 1 Hz - 2 MHz |
| Signal Amplitude | 0.1 - 3.3 V |
| Charging Port | USB Type-C (5V/1A) |
| Dimensions | 167 x 89 x 35 mm |
| Weight | 300 g |
What functions does the FNIRSI 2C23T include?
It integrates a dual-channel digital oscilloscope, a digital multimeter with True RMS, and a function signal generator into a single portable device.
What is the bandwidth and sample rate of the oscilloscope?
The oscilloscope features a 10 MHz analog bandwidth and a real-time sampling rate of 50 MS/s.
What items are included in the package?
The package includes the FNIRSI 2C23T device, a 10X probe, a crocodile clip probe, multimeter test probes, a USB charging cable, and a user manual.
