Digital Clamp Meter Uni-T UT205E True RMS 1000A 1000V
Price: 59.00 €
| Products ID: | 176935 |
|---|---|
| Manufactured by: | Uni-T |
| Availablity: | Ready to Order |
| Delivery Time | 5-10 business days |
| EAN: | 6935750520536 |
Delivery options to:
Choose countryThe Uni-T UT205E digital clamp meter is designed for electrical installation work and equipment diagnostics, enabling fast current measurement without breaking the circuit.
Key Features
- AC current measurement up to 1000 A and AC/DC voltage measurement up to 1000 V
- True RMS capability and automatic range selection
- Supports resistance, capacitance, frequency, and duty cycle measurements
- Equipped with NCV non-contact voltage detection, display backlight, and flashlight
- 42 mm jaw opening and CAT III 1000V / CAT IV 600V safety standard compliance
| Manufacturer | Uni-T |
|---|---|
| Model | UT205E |
| Product type | True RMS clamp meter |
| AC current range | 1000 A ±(2% + 5) |
| AC current frequency response | 50 Hz – 60 Hz |
| AC voltage range | 1000 V ±(1.2% + 3) |
| DC voltage range | 1000 V ±(0.5% + 5) |
| AC voltage frequency response | 40 Hz – 400 Hz |
| Resistance measurement range | 60 MΩ ±(1% + 2) |
| Capacitance measurement range | 60 mF ±(4% + 5) |
| Frequency range | 10 Hz – 1 MHz ±(0.1% + 3) |
| Duty cycle range | 10% – 90% ±(2.6% + 7) |
| Maximum display reading | 6000 |
| Functions | True RMS, NCV, backlight, flashlight, automatic range switching |
| Jaw opening | 42 mm |
| Measurement category | CAT III 1000V / CAT IV 600V |
| Power supply | 3 × 1.5 V (R03) |
| Display dimensions | 43 × 45 mm |
| Dimensions | 272 × 81 × 43.5 mm |
| Weight | 465 g |
| Certifications | CE, UKCA, cETLus |
What is included in the package?
The package includes the clamp meter, one pair of test leads, 3 AAA batteries, and a user manual.
What is the jaw opening size?
The jaw opening is 42 mm, allowing comfortable use with thick cables.
