Smart Energy Sensor 3P+N 63A Modbus RS485
Price: 78.00 €
| Products ID: | 171427 |
|---|---|
| Manufactured by: | Tuya |
| Availablity: | Ready to Order |
| Delivery Time | 5-10 business days |
| EAN: | 9990001083854 |
Delivery options to:
Choose countryThe smart energy sensor is designed for tracking energy consumption in three-phase systems with a neutral wire (3P+N) as well as single-phase installations. It provides real-time measurements of voltage, current, power, energy consumption, and frequency for commercial, industrial, or residential facilities.
Key Features
- Suitable for three-phase (3P+N) and single-phase systems up to 63 A
- Real-time tracking of voltage, current, power, consumption, and frequency
- Phase balance analysis and multi-circuit parameter comparison
- Modbus RTU (RS485) communication interface for system integration
- Flexible installation downstream without occupying DIN rail space
| Max. current (Imax) | 63 A (3P+N) |
|---|---|
| Operating voltage | 208~415V AC |
| Frequency | 50/60 Hz |
| Nominal insulation voltage (Ui) | 400V |
| Energy measurement accuracy | 1%; Class 1 |
| Operating consumption | 0.7W |
| Nominal impulse withstand voltage (Uimp) | 4 kV |
| Overvoltage category | III |
| Communication type | Modbus RS485 |
| Reload button | Yes |
| Indicator light | Yes |
| Protection class | IP20 |
| Operating temperature | -25°C~+60°C |
| Measuring cavity diameter | 9.8mm |
| Dimensions | 46.8x52.8x21.3mm |
What is the maximum supported current of this sensor?
The sensor supports a maximum current of up to 63 A in three-phase (3P+N) installations.
What communication protocol does the device use?
The device uses the Modbus RTU communication protocol over an RS485 interface.
Which electrical parameters can this sensor measure?
It measures voltage, current, power, electricity consumption, frequency, and provides phase balance analysis.
