UNI-T UT116C SMD Tester
Price: 24.30 €
| Products ID: | 176107 |
|---|---|
| Manufactured by: | Uni-T |
| Availablity: | Ready to Order |
| Delivery Time | 5-10 business days |
| EAN: | 6935750511626 |
Delivery options to:
Choose countryThe UNI-T UT116C is a compact measuring instrument designed for fast testing and parameter measurement of SMD components in electronics repair and manufacturing.
Key Features
- Automatic identification and measurement of resistors, capacitors, and diodes
- 180° rotatable movable tip for convenient reading in hard-to-reach spaces
- DC voltage measurement up to 36 V and battery testing at 10 mA load
- Zener diode and LED polarity test up to approximately 21 V / 1 mA
- Circuit continuity buzzer and built-in LED indicator
- 6000-count display with auto range and auto power-off functions
| Manufacturer | UNI-T |
|---|---|
| Model | UT116C |
| Display counts | 6000 |
| Resistance | Up to 60 MΩ |
| Capacitance | Up to 100 mF |
| Diode test | 3.2 V |
| LED / Zener diode test | Approximately 21 V / 1 mA |
| Continuity test | < 50 Ω |
| DC voltage measurement | 36 V |
| Battery test | Load current = 10 mA |
| Auto range | Yes |
| Auto component identification | Yes |
| Auto power off | Yes |
| Power supply | 2 × 1.5 V battery (R03) |
| Display dimensions | 39 mm × 20 mm |
| Color | Red and gray |
| Weight | Approximately 80 g |
| Dimensions | 204 mm × 33 mm × 25 mm |
| Certifications | CE, UKCA |
What is included in the package?
The package includes the UNI-T UT116C SMD tester, battery, and an instruction manual.
What is the maximum capacitance supported by this tester?
The UT116C can measure capacitance up to 100 mF.
Can the measuring tip be adjusted for different angles?
Yes, the tester features a movable tip that rotates 180° to facilitate measurements in hard-to-reach places.
