Besen SQ20-7KW-APP wall-mounted EV charger, 7.2 kW
-4%
Delivery options to:
Choose countryThe Besen SQ20-7KW-APP is a wall-mounted electric vehicle charger for residential and professional use. It offers 7.2 kW output with a single-phase 230 V connection and a maximum current of 32 A.
Charging control and monitoring
Connect to the app via Bluetooth to set the charging time and current, start or stop charging and view charging history. Software updates are also available through the app.
- Display: the 3.5-inch colour LCD shows charging time, voltage, current, temperature and energy consumption in real time.
- Diagnostics: a built-in chip automatically diagnoses and corrects errors that are not caused by hardware faults.
- Protection: against overvoltage, overheating, overload, short circuits, ground faults and lightning strikes. The housing has an IP66 rating.
Interfaces and included items
The listed charging interfaces are SAE J1772, IEC 62196-2 and GB/T. Consider your vehicle’s charging interface and the station’s electrical specifications when choosing a charger.
The set includes the charger, user manual, foldable quick-start card, positioning template, mounting screws and a metal hook.
| Manufacturer | Besen |
|---|---|
| Model | SQ20-7KW-APP |
| Output power | 7.2 kW |
| Input/output voltage | AC 230 V (single-phase) |
| Maximum current | 32 A |
| Frequency | 47–63 Hz |
| Charging interface | SAE J1772, IEC 62196-2, GB/T |
| Display | 3.5-inch colour LCD |
| Ingress protection | IP66 |
| Weight | 6 kg |
| Dimensions | 295 × 195 × 65 mm |
| Ambient temperature | -25 °C to +55 °C |
| Humidity | 0–95%, non-condensing |
| Installation | Wall mounting |
| App connection | Bluetooth |
| App functions | Charging time and current settings, start/stop charging, charging history, software updates |
| Displayed data | Real-time charging time, voltage, current, temperature and energy consumption |
| Protection functions | Overvoltage, overheating, overload, short circuit, ground fault and lightning protection |
| Automatic diagnostics | Diagnoses and corrects errors not caused by hardware faults |
| EAN | 5907085525341 |
|---|
How can I control charging?
Connect to the app via Bluetooth to set the charging time and current, start or stop charging and view your charging history.
What is included?
The charger, user manual, foldable quick-start card, positioning template, mounting screws and a metal hook.
