Besen LX30 22kW APP Wall-Mounted Electric Car Charger

The Besen LX30 is a wall-mounted electric vehicle charger offering up to 22 kW charging power on a three-phase connection and up to 7 kW on a single-phase connection. Supporting up to 32A current, it enables convenient and efficient EV charging with smart app control.

Key Features

Maximum charging power of 22 kW (three-phase) and 7 kW (single-phase)
Smart scheduling and energy monitoring via EVSEMaster APP
Durable PC+ABS housing rated IP66 and IK10 for indoor and outdoor installation
Built-in protection against overheating, overloads, and voltage fluctuations
Three-phase five-wire power support (L1, L2, L3, N, PE)

Manufacturer	Besen
Model	LX30-22kW-APP
Maximum Charging Power	22 kW (three-phase) / 7 kW (single-phase)
Input Voltage	230V/400V AC three-phase five-wire system (L1, L2, L3, N, PE)
Input Current	32A MAX
Input Frequency	50 Hz / 60 Hz
Protection Rating	IP66 / IK10
Housing Material	PC + ABS plastic
Dimensions	264.5 × 235.8 × 124 mm
Weight	5.5 kg
Mobile Application	EVSEMaster APP

Which app is used to control the Besen LX30 charger?

The charger connects to the EVSEMaster APP, allowing users to configure charging schedules, monitor energy consumption, and check real-time device status.

Can this charger be installed outdoors?

Yes, the PC+ABS housing features IP66 weather resistance and IK10 mechanical impact protection, making it suitable for both garage and outdoor installations.

What is included in the package?

The package includes the charger, user manual, quick start foldable card, positioning paper, and mounting screws.
