Besen BS40-11KW-DLB+SOLAR 11 kW EV charger
Delivery options to:
Choose countryThe Besen BS40-11KW-DLB+SOLAR charges electric vehicles at up to 11 kW using a 16 A three-phase supply. This version supports mobile app control, dynamic load balancing and solar charging.
Control and available power
- Mobile app: provides access to charger controls.
- DLB: dynamic load balancing manages the electrical system’s available power.
- Solar charging: supports charging using solar energy.
Housing and mounting
The IP66-rated housing measures 230 × 350 × 95 mm. The charger operates at temperatures from -25 °C to 55 °C and at altitudes up to 2 000 m above sea level. Standby consumption does not exceed 10 W. A wall mount is included, while a mounting post is optional.
Protection features
The charger includes protection against undervoltage, current overload, short circuits, ground faults, overheating and the effects of lightning strikes.
| Manufacturer | Besen |
|---|---|
| Model | BS40-11KW-DLB+SOLAR |
| Power | 11 kW |
| Rated current | 16 A |
| Number of phases | 3 |
| Supply voltage | AC 230/400 V |
| Frequency | 50/60 Hz |
| Protection rating | IP66 |
| Operating temperature | From -25 °C to 55 °C |
| Standby power consumption | ≤10 W |
| Maximum operating altitude | 2 000 m above sea level |
| Dimensions | 230 × 350 × 95 mm |
| Control | Mobile app |
| Dynamic load balancing (DLB) | Supported |
| Solar charging | Supported |
| Protection features | Undervoltage, current overload, short circuits, ground faults, overheating and effects of lightning strikes |
| Mounting | Wall mount included; optional mounting post |
What power supply is required for 11 kW charging?
The charger uses a three-phase supply with a rated current of 16 A. The specified supply voltage is AC 230/400 V at 50/60 Hz.
Is mounting hardware included?
A wall mount is included. A mounting post is optional.
