FNIRSI TSG3020 Function Generator, 2 Channels, 4.3" TFT LCD
Price: 195.90 €
| Products ID: | 177238 |
|---|---|
| Manufactured by: | Fnirsi |
| Availablity: | Ready to Order |
| Delivery Time | 5-10 business days |
| EAN: | 5905156108172 |
Delivery options to:
Choose countryThe FNIRSI TSG3020 is a dual-channel function and arbitrary waveform generator designed for laboratory, workshop, and field electronic testing.
Key Features
- Two independent output channels for simultaneous dual-signal generation
- 200 MSa/s sampling rate and 14-bit vertical resolution for accurate waveform output
- Supports standard and custom arbitrary waveforms via VeriPoint and ZeroSurge technologies
- Six modulation types (AM, FM, PM, FSK, ASK, PSK) and linear/logarithmic frequency sweep
- Built-in 7-digit frequency counter and 4.3-inch color TFT-LCD touchscreen
- Non-volatile memory storing up to 24 custom arbitrary waveforms
| Manufacturer | FNIRSI |
|---|---|
| Model | TSG3020 |
| Maximum output frequency | 30 mHz |
| Sampling rate | 200 MSa/s |
| Vertical resolution | 14 bits |
| Channels | 2 |
| Maximum output amplitude | 20 Vpp (10 mHz) |
| Sine Wave Frequency | 1 µHz–24 MHz |
| Square Wave Frequency | 1 µHz–24 MHz |
| Pulse wave frequency | 1 µHz–24 MHz |
| Modulation types | AM, FM, PM, FSK, ASK, PSK |
| Sweep modes | Linear sweep, logarithmic sweep |
| Built-in frequency counter | 7-digit |
| Display screen | 4.3” TFT LCD, 480 x 272 |
What is included in the FNIRSI TSG3020 package?
The package includes the function generator, charging adapter, Type-C charging cable, data cable, measuring lead, alligator clips, and user manual.
Which modulation modes does the generator support?
The device supports six modulation types: AM, FM, PM, FSK, ASK, and PSK.
