Minis Forum MS-01-S1390 Mini PC Intel Core i9-13900H Barebone
Price: 775.50 €
| Products ID: | 175296 |
|---|---|
| Manufactured by: | Minis Forum |
| Availablity: | Ready to Order |
| Delivery Time | 5-10 business days |
| EAN: | 4897118831949 |
Delivery options to:
Choose countryThe Minis Forum MS-01-S1390 is a compact barebone mini PC powered by a 14-core Intel Core i9-13900H processor, designed for demanding multitasking, editing, and database workloads. Please note that RAM and SSD are not included.
Key Features
- Processing Power: 14-core, 20-thread Intel Core i9-13900H processor reaching up to 5.4 GHz.
- Memory Support: DDR5 RAM expandable up to 64 GB at 4800 MHz.
- Flexible Storage: Dual M.2 NVMe SSD slots (2280/22110) up to 4 TB, with U.2 drive and RAID0/RAID1 support.
- High-Speed Connectivity: Dual 10 Gbps SFP+ ports, dual 2.5 Gbps RJ45 ports, and a full-size PCIe 4.0 slot.
- Advanced Cooling: Cold Wave 2.0 cooling system with liquid metal and active RAM and SSD cooling.
| Manufacturer | Minisforum |
|---|---|
| Model | MS-01-S1390 |
| Processor | Intel Core i9-13900H |
| Architecture | Raptor Lake-H |
| Cores | 14 |
| Threads | 20 |
| Maximum Frequency | 5.4 GHz |
| Processor Technology | Intel 7 |
| RAM | 0 GB (DDR5, up to 64 GB 4800 MHz supported) |
| Storage | 0 GB (Supports 2x M.2 22110/2280 NVMe SSD up to 4 TB) |
| Graphics | Intel Iris Xe Graphics |
| Network Ports | 2x RJ45 2.5G, 2x SFP+ 10Gbps |
| Wireless Connectivity | M.2 2230 (Wi-Fi 6E, Bluetooth 5.2 support) |
| Cooling System | Cold Wave 2.0 (liquid metal with active RAM and SSD cooling) |
| Power Supply | 19V / 9.47A |
| Operating System | None |
Does this mini PC include RAM and SSD storage?
No, this is a barebone system and does not come with pre-installed RAM (0 GB) or SSD storage (0 GB).
What storage configurations are supported?
It supports two M.2 NVMe SSDs (2280/22110) up to 4 TB, U.2 drives, and RAID0/RAID1 configurations.
