Mini PC Minis Forum M1 Pro-125H Intel Core Ultra 5 125H Barebone
Price: 504.30 €
| Products ID: | 176047 |
|---|---|
| Manufactured by: | Minis Forum |
| Availablity: | Ready to Order |
| Delivery Time | 5-10 business days |
| EAN: | 4897118834391 |
Delivery options to:
Choose countryThe Minis Forum M1 Pro-125H is a compact barebone mini PC powered by a 14-core Intel Core Ultra 5 125H processor and integrated Intel Arc graphics. It supports dual-channel DDR5 5600 MHz memory up to 128 GB and two M.2 NVMe PCIe 4.0 SSDs up to 4 TB.
Key Features
- Intel Core Ultra 5 125H processor with 14 cores, 18 threads, and boost clock up to 4.5 GHz
- Integrated Intel Arc graphics with an OcuLink port for external GPU (eGPU) connection
- Multi-display support for up to 4 monitors via HDMI 2.1, DisplayPort 1.4, and dual USB4 ports
- High-speed network connectivity with Wi-Fi 7, Bluetooth 5.4, and 2.5G Ethernet LAN
- Dual-fan cooling system with pure copper heatpipes
- Compact 600 g chassis with included VESA mounting bracket
| Manufacturer | Minis Forum |
|---|---|
| Model | M1 Pro-125H |
| Processor | Intel Core Ultra 5 125H |
| Cores / Threads | 14 / 18 |
| Base / Max Frequency | 1.2 GHz / 4.5 GHz |
| Graphics | Intel Arc graphics |
| Memory Type | DDR5 (2x SO-DIMM) |
| Max RAM Capacity | Up to 128 GB (5600 MHz) |
| Storage Slots | 2x M.2 2280 NVMe SSD (PCIe 4.0 x4, up to 4 TB) |
| Wireless Connectivity | Wi-Fi 7, Bluetooth 5.4 |
| Ethernet (LAN) | 2.5 Gigabit LAN (RJ45, i226-v) |
| Video Outputs | 1x HDMI 2.1, 1x DP 1.4, 2x USB4 |
| Expansion Port | OcuLink |
| USB Ports | 2x USB3.2 Gen2 Type-A, 1x USB2.0 Type-A, 2x USB4 |
| Audio Ports | 3.5 mm combo jack |
| VESA Mounting | Supported |
| Power Supply | 19V 6.32A 120W |
| Dimensions | 128 x 126 x 52 mm |
| Weight | 0.6 kg |
How many displays can be connected simultaneously?
The M1 Pro-125H supports up to 4 simultaneous displays using HDMI 2.1, DisplayPort 1.4, and the two USB4 ports.
What memory and storage configurations are supported?
It supports up to 128 GB of dual-channel DDR5 5600 MHz RAM (2x SO-DIMM) and up to two M.2 2280 PCIe 4.0 NVMe SSDs totaling up to 4 TB.
Can an external graphics card be attached to this mini PC?
Yes, it includes a dedicated OcuLink port designed for connecting an external GPU (eGPU).
