Mini PC GMKtec M8 AMD Ryzen 5 PRO 6650H 16GB 1TB SSD Windows 11 Pro
Gmktec
| Products ID: | 196721 |
|---|---|
| Manufactured by: | Gmktec |
| Availablity: | Ready to Order |
| Delivery Time | 5-12 business days |
| EAN: | 6972570964461 |
Delivery options to:
Choose country
The GMKtec M8 is a compact mini PC powered by the 6-core, 12-thread AMD Ryzen 5 PRO 6650H processor with clock speeds up to 4.5 GHz and integrated AMD Radeon 660M graphics, engineered for demanding office, technical, and multimedia workloads.
Memory and High-Speed Storage
This mini computer comes equipped with 16 GB of LPDDR5 RAM running at up to 6400 MT/s and a pre-installed 1 TB PCIe 3.0 M.2 2280 SSD loaded with Windows 11 Pro. Internal storage can be expanded via two additional PCIe 4.0 x4 slots supporting up to 8 TB per drive.
Triple Display and Extensive Connectivity
The device supports up to three simultaneous 8K displays at 60 Hz via HDMI 2.0, DisplayPort 1.4, and a full-featured USB4 port. Connectivity also includes an OCuLink port for external desktop GPUs, three USB 3.2 ports, dual 2.5G LAN ports, Wi-Fi 6E, and Bluetooth 5.2.
Dual-Fan Cooling System
Efficient thermal dissipation is achieved through a cooling setup with dual fans and copper heat pipes. Users can switch between three performance modes: quiet (28W), balanced (35W), and high-performance (40W).
| Manufacturer | GMKtec |
|---|---|
| Model | M8 |
| Dimensions | 110 × 108 × 64 mm |
| Case Material | Metal, plastic |
| Weight | 482 g |
| Processor | AMD Ryzen 5 PRO 6650H |
| Max. clock speed | 4.5 GHz |
| Power consumption | 28 W / 35 W / 40 W (operating modes) |
| RAM | LPDDR5 6400 MT/s |
| RAM capacity | 16 GB |
| eMMC | No |
| SSD | M.2 2280 1 TB (PCIe 3.0, pre-installed), 2 x M.2 2280 PCIe 4.0 x4 (supports up to 2 × 8 TB) |
| 2.5" HDD/SSD support | No |
| TF card reader | No |
| Real-time clock | Supported |
| BIOS support | Yes |
| TPM | TPM 2.0 support |
| Video outputs | 1 x HDMI 2.0, 1 x DisplayPort 1.4, 1 x USB 4.0 (via DisplayPort) |
| Status indicator | Power status LED |
| Wi-Fi | Wi-Fi 6E |
| Interface type | PCIe |
| Bluetooth | Bluetooth 5.2 |
| Bluetooth interface | BT5.2 |
| Built-in Wi-Fi | Yes |
| Built-in Bluetooth | Yes |
| LAN | 2 x Gigabit LAN (2.5G / 1G / 100M / 10M) |
| USB 2.0 | 1 x USB-A 2.0 |
| USB 3.2 | 3 x USB-A 3.2 Gen 2 |
| External Storage Expansion | No |
| Audio/Video Outputs | 1 × HDMI 2.0, 1 × DP 1.4, 1 × USB4 (DisplayPort), 1 × OCuLink |
| Ethernet Ports | 2 x RJ45 (2.5G) |
| Data Transfer | Yes |
| Buttons | Power button x1 |
| DC IN | Yes |
| Audio Input/Output | 1 x 3.5 mm headphone jack (CTIA) |
| Antennas | Built-in dual antenna |
| Operating system | Windows 11 Pro pre-installed, Linux support |
| Operating temperature | 0–40 ℃ |
| Storage temperature | 0–40 ℃ |
| Humidity | 35%–80% RH, non-condensing |
| Power supply | DC IN 20V 5A = 100W |
| IR Remote Control | No |
| VESA | Yes |
| Radio Bands | Wi-Fi 2.4 GHz / Wi-Fi 5 GHz / Wi-Fi 6E / Bluetooth |
| Max. Transmit Power | 18.5 dBm (AMD RZ616 Wi-Fi Module Theoretical Values) |
Which operating system comes pre-installed on the GMKtec M8?
The device comes with Windows 11 Pro pre-installed and also offers Linux compatibility.
How many external displays does the GMKtec M8 support?
It supports up to three displays simultaneously at up to 8K resolution at 60 Hz using HDMI 2.0, DisplayPort 1.4, and the USB4 port.
Can the internal SSD storage be expanded?
Yes, in addition to the pre-installed 1 TB drive, there are two M.2 2280 PCIe 4.0 x4 slots that support drives up to 8 TB each.
