ANCEL ANJ600 Fuel Injector Cleaner and Tester

The ANCEL ANJ600 is a dedicated device for cleaning and testing automotive fuel injectors, equipped with a digital display, microprocessor-controlled fuel pressure, and an ultrasonic cleaner. It supports both electromagnetic (such as EFI and GDI) and piezoelectric injectors.

Key Features and Capabilities

100 W ultrasonic cleaner (38–39 kHz) for removing carbon deposits and contaminants
Adjustable operating fuel pressure from 0 to 8 bar
Engine simulation range from 100 to 9,900 RPM with pulse width up to 30 ms
Spray pattern/uniformity, leakage, and injection flow rate diagnostics
Three automatic test modes and an automatic fuel drain feature
Motherboard support for low-resistance injectors down to 1Ω
2,400 ml fuel tank capacity

Manufacturer	ANCEL
Model	ANJ600
Device Type	Fuel injector cleaning and testing device
Input Power	230 W
Ultrasonic Cleaner Power	100 W (38–39 kHz)
Operating Pressure	0–8 bar (adjustable)
Fuel Tank Capacity	2,400 ml
Simulated RPM Range	100–9,900 RPM
Pulse Width	0–30 ms
Time Range	5–300 s
Resistance Test Accuracy	0.1 Ω
Supported Injectors	Electromagnetic (EFI, GDI, etc.), piezoelectric injectors
Display	Digital screen
Operating Temperature	-10°C to 40°C

What types of injectors does the ANCEL ANJ600 support?

It supports electromagnetic injectors (including EFI and GDI), piezoelectric injectors, and low-resistance models down to 1Ω.

What diagnostic tests can be performed with the ANJ600?

The device performs spray pattern and uniformity tests, needle valve leak tests, 15-second injection volume tests, and automatic engine simulation sequences.

What is the capacity and operating pressure range?

The fuel tank has a capacity of 2,400 ml, and the operating fuel pressure is adjustable between 0 and 8 bar.
