Besen BS20 22kW Wall-Mounted EV Charger with App Control

Q: What charging power does the Besen BS20 support?

The Besen BS20 supports up to 7.2 kW in single-phase mode and up to 22 kW in three-phase mode with a maximum current of 32 A.

Q: How can the charger be controlled remotely?

The charger connects to your smartphone via Bluetooth using the EVSEMaster app, allowing you to start or stop charging, set schedules, and view history.

Q: What items are included in the package?

The package includes the charger, user manual, fold-out quick start guide, positioning paper, mounting screws, and a metal hanger.

-4%

Besen BS20 22kW Wall-Mounted EV Charger with App Control — primary image

Besen BS20 22kW Wall-Mounted EV Charger with App Control — image 2

Besen BS20 22kW Wall-Mounted EV Charger with App Control — image 3

Price: 370.40 €356.00 €

Products ID:	148650
Manufactured by:	Besen
Availablity:	Ready to Order
Delivery Time	5-10 business days
EAN:	5906168438783

Delivery options to:

Choose country

Besen BS20 22kW Wall-Mounted EV Charger with App Control

The Besen BS20 is a wall-mounted electric vehicle charger delivering up to 7.2 kW in single-phase mode and up to 22 kW in three-phase mode, designed for residential garages and commercial parking spaces.

Key Features

Maximum output power up to 22 kW with 32 A maximum current
3.5-inch color LCD display showing real-time charging status
Smart control and scheduling via the EVSEMaster mobile app
Durable stainless steel and aluminum construction with IP66 and IK10 ratings
Integrated 5 m charging cable for convenient vehicle connection
Comprehensive protection suite including Type A and Type A+ 6 mA DC RCD

Manufacturer	Besen
Model	BS20
Input / Output voltage	AC 230V / 400V
Input frequency	47 ~ 63Hz
Output power	7.2kW (single-phase) / 22kW (three-phase)
Max. output current	32 A
Connector type	SAE J1772, IEC 62196-2, GB/T
Cable length	5 m
Protection rating	IP66
Impact resistance	IK10
Display	3.5-inch color LCD
Housing material	Stainless steel, aluminum
Standby power consumption	< 8 W
Ambient temperature	-25°C ~ 55°C
Ambient humidity	0–95% (non-condensing)

What charging power does the Besen BS20 support?

The Besen BS20 supports up to 7.2 kW in single-phase mode and up to 22 kW in three-phase mode with a maximum current of 32 A.

How can the charger be controlled remotely?

The charger connects to your smartphone via Bluetooth using the EVSEMaster app, allowing you to start or stop charging, set schedules, and view history.

What items are included in the package?

The package includes the charger, user manual, fold-out quick start guide, positioning paper, mounting screws, and a metal hanger.
