Creality Halot X1 Combo 3D Printer with AFU Module

Creality Halot X1 Combo 3D Printer with AFU Module — image 3

Creality Halot X1 Combo 3D Printer with AFU Module — image 4

Price: 531.50 €

Products ID:	176067
Manufactured by:	Creality
Availablity:	Ready to Order
Delivery Time	5-10 business days
EAN:	6975471800326

Delivery options to:

Choose country

Creality Halot X1 Combo 3D Printer with AFU Module

The Creality Halot X1 Combo is an LCD resin 3D printer equipped with a 16K screen and an intelligent Auto Feed Unit (AFU) for precise, automated resin 3D printing.

Key Features

16K monochrome LCD screen with 15120 × 6230 resolution and 14 × 19 µm pixel size
Included Auto Feed Unit (AFU) for automated feeding, draining, and resin heating
Spacious build volume of 211.68 × 118.37 × 200 mm
Automatic platform calibration with no manual leveling required
Honeycomb Matrix light source with 92-zone intelligent exposure control
Print speeds up to 170 mm/h with 0.01-0.2 mm layer thickness
3.98-inch touchscreen interface for convenient operation

Printing Technology	LCD
Screen Resolution	16K (15120 × 6230 px)
Pixel Size	14 × 19 µm
Build Volume	211.68 × 118.37 × 200 mm
Print Speed	Up to 170 mm/h
Layer Thickness	0.01-0.2 mm
Z-Axis Accuracy	0.01 mm
Light Source	Honeycomb Matrix
Exposure Intensity	6500 ±10% µW/cm²
Display	3.98-inch capacitive touchscreen
Data Transfer	USB / Wi-Fi
Software	HALOT BOX / ChituBox
Power Consumption	350 W
Input Voltage	100-120 V~ / 200-240 V~, 50/60 Hz
Printer Dimensions	344 × 331 × 434 mm
Weight	12.75 kg

What is included in the package?

The package includes the 3D printer and the AFU (Auto Feed Unit) module.

What does the Auto Feed Unit (AFU) do?

The AFU automates resin handling by feeding and draining resin, reading material RFID tags to download cloud profiles, heating resin to optimal temperature, and monitoring fluid levels in real time.

Does the printer require manual bed leveling?

No, the printer features automated platform calibration and does not require manual leveling.
