QIDI Max 4 3D Printer, 390 × 390 × 340 mm, CoreXY

QIDI Max 4 3D Printer, 390 × 390 × 340 mm, CoreXY — image 3

QIDI Max 4 3D Printer, 390 × 390 × 340 mm, CoreXY — image 4

QIDI Max 4 3D Printer, 390 × 390 × 340 mm, CoreXY — image 5

Price: 1204.30 €

Products ID:	183924
Manufactured by:	QiDi
Availablity:	Ready to Order
Delivery Time	5-10 business days
EAN:	744581222559

Delivery options to:

Choose country

QIDI Max 4 3D Printer, 390 × 390 × 340 mm, CoreXY

The QIDI Max 4 is an advanced CoreXY 3D printer with a large workspace and active chamber heating, designed to handle both standard filaments and demanding engineering materials.

Key Features

Generous 390 × 390 × 340 mm build volume for printing large parts in a single piece
High print head temperature up to 370°C suitable for technical and composite filaments
3rd generation active chamber heating reaching up to 65°C to eliminate warping
Rapid operation with print speeds up to 800 mm/s and acceleration up to 30 000 mm/s²
Automatic bed leveling via load cell sensor and integrated 1080p timelapse camera
3-stage air filtration system combining G3 pre-filter, HEPA H12, and activated carbon

Manufacturer	QiDi
Model	Max 4
Working area	390 × 390 × 340 mm
Printer dimensions	558 × 578 × 612 mm
Weight	40 kg
Maximum head temperature	up to 370°C
Maximum table temperature	up to 120°C
Chamber temperature	up to 65°C (active heating – 3rd generation)
Maximum print speed	800 mm/s
Maximum acceleration	30 000 mm/s²
Extruder	Direct Drive, hardened steel double gears
Supported filaments	PLA, ABS, ASA, PETG, TPU, PA, PC, carbon fiber and glass fiber composites
Filament diameter	1.75 mm
Material flow	40 mm³/s
Automatic leveling	yes (load cell sensor in hotend)
Filament sensor	Yes – filament end detection
Air filter	3-in-1: G3 + HEPA H12 + activated carbon
Camera	1080p with timelapse support
Connectivity	Wi-Fi 2.4/5 GHz, Ethernet, USB
Memory	32 GB eMMC + USB 2.0
Screen	5" touchscreen 800 × 480
Supported file formats	STL, OBJ, 3MF, STEP, STP
Software	QIDI Studio, OrcaSlicer, PrusaSlicer, and others
Power supply	110V / 220–240V AC, 50/60 Hz
Rated power	150 W + 500 W (chamber heating) + 700 W (heating table)

What is the build volume of the QIDI Max 4?

The printer features a working area of 390 × 390 × 340 mm, enabling you to print large projects in one piece without sectioning.

What maximum temperatures can the printer reach?

The print head reaches up to 370°C, the heating table reaches up to 120°C, and the actively heated chamber heats up to 65°C.

What items are included in the package?

The package includes filament holders and covers, a case door handle, maintenance oil, tools (7 mm wrench, flat screwdriver, Allen key set H1.27–H3), print bed adhesive, a scraper, power and Ethernet cables, a spare parts kit, and a USB flash drive.
