TerraMaster U8-500 Plus NAS File Server, Intel Core i7-1255U, 16 GB RAM, 8 Bays

The TerraMaster U8-500 Plus is a high-performance NAS file server powered by a 10-core Intel Core i7-1255U processor, 16 GB of DDR5 memory, and 8 drive bays for centralized enterprise data storage and backups.

Key Features

Intel Core i7-1255U 10-core processor with Turbo Boost up to 4.7 GHz.
16 GB DDR5 4800 MHz memory, expandable up to 64 GB via two SODIMM slots.
8 drive bays supporting 3.5"/2.5" SATA HDDs and SSDs with up to 176 TB total capacity.
Dual 10GbE RJ-45 network ports with link aggregation support.
Two M.2 2280 NVMe PCIe 4.0 x4 slots for SSD cache or fast storage pools.
Hot-swap drive support and multiple RAID levels (TRAID, TRAID+, JBOD, RAID 0, 1, 5, 6, 10).

Manufacturer	TerraMaster
Model	U8-500 Plus
Processor	Intel Core i7-1255U
Number of cores	10
Turbo frequency	up to 4.7 GHz
RAM	16 GB DDR5 4800 MHz
Maximum RAM	64 GB DDR5
Number of drive bays	8
Supported Drives	3.5" SATA HDD, 2.5" SATA HDD, 2.5" SATA SSD
Maximum Internal Capacity (Raw Storage)	176 TB (8 × 22 TB)
M.2 Slots	2 × M.2 2280 NVMe PCIe 4.0 x4
Network ports	2 × 10GbE RJ-45
USB ports	3 × USB 3.1 Type-A, 1 × USB 3.1 Type-C (10 Gb/s)
HDMI	1
Expansion slot	1 × PCIe 3.0 x4
Supported RAID	TRAID, TRAID+, JBOD, RAID 0, 1, 5, 6, 10
File system	Btrfs, EXT4
Hot Swap	Yes
Dimensions	88 × 440 × 384 mm
Weight	6.9 kg
Power Supply	250 W

What drive types are supported by the TerraMaster U8-500 Plus?

The server supports 3.5" SATA HDDs, 2.5" SATA HDDs, and 2.5" SATA SSDs across 8 hot-swappable bays, along with two M.2 2280 NVMe PCIe 4.0 x4 SSD slots.

What is the maximum supported memory capacity?

The system comes equipped with 16 GB DDR5 RAM and can be expanded up to 64 GB DDR5 using its two SODIMM slots.

What is included in the package?

The package includes the TerraMaster U8-500 Plus NAS server, power cord, RJ-45 network cable, quick start guide, warranty information, and a set of mounting screws.
