TerraMaster F8 SSD Plus NAS Server, Intel Core i3-N305, 16 GB RAM, 8-Bay M.2 NVMe, 10GbE

Price: 873.80 €

Products ID:	177534
Manufactured by:	Terramaster
Availablity:	Ready to Order
Delivery Time	5-10 business days
EAN:	6939236145855

Delivery options to:

Choose country

TerraMaster F8 SSD Plus NAS Server, Intel Core i3-N305, 16 GB RAM, 8-Bay M.2 NVMe, 10GbE

The TerraMaster F8 SSD Plus is a compact all-flash NAS file server powered by an 8-core Intel Core i3-N305 processor, 16 GB of DDR5 memory, and 8 bays for M.2 NVMe SSDs. It features a 10GbE network port, hardware-accelerated 4K video decoding, and flexible RAID options for reliable data storage, backup, and multimedia management.

Key Features

8 M.2 NVMe 2280 slots supporting up to 64 TB total capacity
10GbE RJ-45 port delivering sequential transfer speeds up to 1020 MB/s
Intel Core i3-N305 8-core processor with 16 GB DDR5 4800 MHz RAM
Hardware 4K 60 FPS video decoding via Intel UHD Graphics
Quiet active cooling system maintaining noise levels as low as 18.5 dB(A)
TOS 6 operating system with Docker support, snapshots, and cloud sync

Manufacturer	TerraMaster
Model	F8 SSD Plus
Processor	Intel Core i3-N305
Number of cores / threads	8 cores / 8 threads
Maximum clock speed	up to 3.8 GHz
Graphics	Intel UHD Graphics
Hardware video decoding	H.264, H.265, MPEG-4, VC-1, 4K 60 FPS
RAM	16 GB DDR5 4800 MHz non-ECC SODIMM
Maximum supported RAM	32 GB DDR5
Number of drive bays	8
Supported storage media	M.2 NVMe 2280 SSD (M-Key)
Maximum capacity	up to 64 TB (8 × 8 TB)
Network port	1 × 10GbE RJ-45
USB ports	3 × USB 3.2 Gen 2 (10 Gb/s)
HDMI port	1
Supported file systems (internal)	Btrfs, EXT4
Supported file systems (external)	EXT3, EXT4, NTFS, FAT32, HFS+, Btrfs
Supported RAID configurations	TRAID, TRAID+, JBOD, RAID 0, RAID 1, RAID 5, RAID 6, RAID 10
Noise level	18.5 dB(A)
Power consumption	72 W
Dimensions	177 × 60 × 140 mm
Weight	0.6 kg
Operating system	TOS 6

What storage drives are compatible with the TerraMaster F8 SSD Plus?

The server supports M.2 NVMe 2280 SSDs (M-Key) across its 8 drive bays, allowing a maximum total storage capacity of up to 64 TB (8 × 8 TB).

What is included in the package?

The package includes the TerraMaster F8 SSD Plus NAS server, AC adapter, power cord, RJ-45 network cable, quick start guide, warranty document, and a set of mounting screws.
