Smart Home Control Panel 10.1” Shelly Wall Display XL WiFi/BLU, Gray
323.70 €
Products ID: 176004
In supplier warehouse
Available to order: 10+ pcs.
Delivery Time 5–12 business days
Delivery options to:
Choose countryThe Shelly Wall Display XL is a wall-mounted control panel featuring a 10.1-inch touchscreen and built-in relay, designed for managing smart home devices and automated scenes.
Key Features
- 10.1-inch HD color 5-point capacitive touchscreen with 1280 × 752 resolution
- Quad-core Rockchip RK3566 processor, 2 GB RAM, and 16 GB Flash running Android 11
- Built-in relay supporting direct device control up to 1,500 W (240 V~, 5 A)
- Four customizable physical buttons for quick access to key scenes and functions
- Wireless connectivity with dual-band Wi-Fi 6 (2.4/5 GHz) and Bluetooth 5.4
- Integrated 2 × 2 W stereo speakers for media playback and Internet radio
- Integrates with Shelly Smart Control, Home Assistant, and MQTT
| Manufacturer | Shelly |
|---|---|
| Model | WallDisplayXLG |
| Display | 10.1", 5-point capacitive touchscreen (G+FF) |
| Display Resolution | 1280 × 752 px |
| Processor | Rockchip RK3566 Quad-core Cortex-A55 |
| RAM | 2 GB |
| Flash Memory | 16 GB |
| Operating System | Android 11 |
| Power Supply | 100-240 V~ 50/60 Hz or USB-C 5 V⎓ / 3 A |
| Max Switching Current & Voltage | 5 A / 240 V~ |
| Speakers | 2 × 2 W |
| Connectivity | Wi-Fi 6 Dual Band (2.4/5 GHz), Bluetooth 5.4 |
| Sensors | Light sensor, proximity sensor (≤ 1 m) |
| Microphone | Four-microphone array |
| Dimensions (H × W × D) | 155.8 × 272.5 × 38.3 mm |
| Weight | 920 g |
| Mounting | Wall box (EU standard) |
| Housing Material | Metal, PC coated, glass |
| Color | Gray |
| EAN | 3800238071691 |
|---|
What are the display specifications of the Shelly Wall Display XL?
It features a 10.1-inch 5-point capacitive touchscreen with a resolution of 1280 × 752 pixels.
What load capacity does the built-in relay support?
The integrated relay supports directly controlling devices up to 1,500 W with a maximum current of 5 A at 240 V~.
Which smart home systems and protocols are supported?
The device supports the Shelly Smart Control application, Home Assistant, MQTT, and Webhooks.
