Reolink D340W 5MP 2K+ Wi-Fi Video Doorbell
Reolink
| Products ID: | 195828 |
|---|---|
| Manufactured by: | Reolink |
| Availablity: | Ready to Order |
| Delivery Time | 7-15 business days |
| EAN: | 6975253983315 |
Delivery options to:
Choose country
The Reolink D340W is a wired smart video doorbell offering 2K+ (5 MP) resolution and dual-band Wi-Fi connectivity for stable outdoor monitoring.
Sharp 2K+ Clarity and Wide View
Equipped with a 1/2.7" CMOS sensor, the camera captures video at 2560 x 1920 pixels at 20 fps. A wide 180° diagonal and 134° horizontal field of view ensures extensive entryway coverage, while integrated infrared LEDs provide clear night vision.
Person Detection and Two-Way Audio
On-device person detection with customizable motion zones helps filter relevant events. The integrated microphone and speaker enable direct two-way conversations with visitors, and the included indoor chime delivers audible alerts.
Flexible Network and Wired Power
The doorbell operates on 2.4 GHz and 5 GHz Wi-Fi networks as well as a 10/100 Mbps RJ-45 Ethernet port. It features IP65 weather resistance, support for up to 256 GB microSD cards, and connects to 12-24 V AC doorbell wiring.
| Image Sensor | 1/2.7" CMOS |
|---|---|
| Resolution | 2560 x 1920 (5 MP) |
| Frame Rate | 20 fps |
| Lens | 2.26 mm / F2.0 with IR cut |
| Field of View | 134° horizontal, 97° vertical, 180° diagonal |
| Wi-Fi | 2.4 GHz & 5 GHz dual band (IEEE 802.11 a/b/g/n) |
| Encryption | WPA-PSK/WPA2-PSK |
| Ethernet Port | 1x RJ-45 (10 / 100 Mbps) |
| Power Supply | 12-24 V AC 50 / 60 Hz |
| Weather Resistance | IP65 |
| Memory Card Slot | microSD up to 256 GB |
| Video Compression | H.264 |
| Smart Home Compatibility | Google Assistant |
| Doorbell Dimensions | 133 x 48 x 23 mm |
| Doorbell Weight | 96 g |
| Chime Dimensions | 86.5 x 29 x 66 mm |
| Color | Black |
How is the Reolink D340W powered?
It is wired to an existing doorbell power source or transformer operating at 12-24 V AC (50 / 60 Hz).
What storage options are supported for recordings?
The doorbell includes a microSD card slot supporting cards up to 256 GB.
Is an angle wedge included for installation?
Yes, a 15° wedge is included in the package for adjusting the viewing angle during mounting.
