PTZ Dome Network Camera SD4D425MB-HNR 4 MP 25x Optical Zoom PoE
Price: 455.90 €
| Products ID: | 178227 |
|---|---|
| Manufactured by: | Dahua Technology Co., Ltd |
| Availablity: | Ready to Order |
| Delivery Time | 5-10 business days |
| EAN: | 6939554962479 |
Delivery options to:
Choose countryThe SD4D425MB-HNR network PTZ dome camera delivers 4 MP video monitoring with 25x optical zoom and advanced intelligent analytics.
Key Features
- 4 MP Resolution: 1/2.8" CMOS sensor capturing video at 2560 x 1440 resolution.
- 25x Optical Zoom: 5 mm–125 mm focal length lens for detailed long-range monitoring.
- Dual Illumination: IR and warm light illuminators covering distances up to 100 m.
- PTZ Mechanism: 360° endless pan rotation and –15° to +90° tilt range.
- Intelligent Detection: perimeter protection, face detection, SMD 4.0, and WizTracking auto-tracking.
- Robust Construction: IP67 ingress protection rating and an operating temperature range of –40 °C to +70 °C.
| Image Sensor | 1/2.8" CMOS |
|---|---|
| Pixel | 4 MP |
| Max. Resolution | 2560 (H) x 1440 (V) |
| ROM | 4 GB |
| RAM | 1 GB |
| Electronic Shutter Speed | 1 s–1/30 000 s |
| Scanning System | Progressive |
| Min. Illumination | 0.005 lux@F1.6 (Color, 30 IRE); 0.0005 lux@F1.6 (B/W, 30 IRE); 0 lux (illuminator on) |
| Illumination Distance | 100 m (IR); 100 m (Warm light) |
| Illuminator Number | 2 (IR); 2 (Warm light); 2 (Dual-core light) |
| Focal Length | 5 mm–125 mm |
| Max. Aperture | F1.6–F3.6 |
| Field of View | H: 54.1°–3.4°; V: 31.4°–1.9°; D: 61.1°–3.9° |
| Optical Zoom | 25x |
| Focus Control | Auto; semi-auto; manual |
| Close Focus Distance | 0.1 m–0.5 m |
| Pan/Tilt Range | Pan: 0° to 360° endless; Tilt: –15° to +90°, auto flip 180° |
| Preset | 300 |
| IVS (Perimeter Protection) | Tripwire; intrusion; crossing fence detection; loitering detection; abandoned/missing object; fast moving; parking detection; people gathering; human alarm classification; linkage tracking |
| Face Detection | Supports face detection, optimization, capturing pictures, uploading snapshots, and attribute extraction |
| Smart Tracking | WizTracking |
| SMD | SMD 4.0 |
| Video Compression | Smart H.265+; H.265; Smart H.264+; H.264B; H.264M; H.264H; MJPEG |
| Video Frame Rate | Main stream: 4M/3M/1080p/1.3M/720p@(1–25/30 fps) |
| WDR | 120 dB |
| Noise Reduction | 2D NR; 3D NR |
| Digital Zoom | 16x |
| Network Port | 1 x RJ-45 (10/100 Base-T) |
| Interoperability | ONVIF (Profile S & Profile G & Profile T); CGI; SDK |
| Storage | Micro SD card (512 GB); FTP/SFTP; NAS |
| Audio I/O | 1/1 |
| Alarm I/O | 2/1 |
| Power Supply | 12 VDC, 3 A ± 10%; PoE (802.3at) |
| Power Consumption | DC: Max. 20 W; PoE: Max. 23 W |
| Operating Temperature | –40 °C to +70 °C |
| Protection | IP67; TVS 6000 V lightning proof |
| Product Dimensions | 270.4 mm x 160 mm |
| Net Weight | 2.4 kg |
What is the optical zoom capacity of this camera?
The camera features 25x optical zoom with a 5 mm to 125 mm focal length lens.
What is the maximum supported Micro SD card size?
The camera supports Micro SD cards up to 512 GB.
How is the camera powered?
It can be powered via a 12 VDC (3 A) power supply or through PoE (802.3at).
