EcoFlow Alternator Charger 600W Car Charger
Ecoflow
| Products ID: | 193228 |
|---|---|
| Manufactured by: | Ecoflow |
| Availablity: | Ready to Order |
| Delivery Time | 5-12 business days |
| EAN: | 4895251648325 |
Delivery options to:
Choose country
The EcoFlow Alternator Charger 600W is a smart car charger designed to use energy generated by your vehicle alternator to rapidly recharge portable power stations while driving. With up to 600 W of output power, it can replenish approximately 1 kWh of energy in about 1.9 hours, offering a much faster alternative to traditional cigarette lighter socket charging.
Three Operating Modes
The charger features versatile modes tailored to different mobile power needs:
- Power Station Charging: delivers up to 600 W to replenish portable stations on the go.
- Battery Maintenance Mode: supplies up to 100 W to help maintain correct vehicle starter battery voltage.
- Reverse Charging Mode: transfers power from your power station back to the starter battery to prevent discharge when operating auxiliary 12V equipment.
Comprehensive Electrical Protection
Engineered for electrical safety, the charger features reverse polarity protection, overcurrent protection, short-circuit protection, overvoltage/undervoltage protection, and overheat protection. An inline 125 A fuse provides additional circuit security, while the IP4X-rated enclosure protects against dust ingress. Passive heat dissipation allows silent thermal management, and EMC Class B compliance ensures no interference with vehicle electronics.
Easy Installation and Real-Time Monitoring
A Plug & Play design and braided cables make vehicle installation simple and abrasion-resistant. The charger activates automatically with the engine ignition wire. Users can track voltage, battery levels, and estimated charging times in real time via the EcoFlow app or directly through Apple CarPlay and Android Auto.
| Manufacturer | EcoFlow |
|---|---|
| Name | Alternator Charger 600W |
| Model | EF-AC-002 |
| Weight | Approx. 1.1 kg |
| Dimensions | 224 × 153 × 38 mm |
| Wi-Fi | Yes |
| Solar input | N/A |
| Bluetooth | Yes |
| Charging mode – ALT IN input | 12 V / 24 V (11-31 V), 45 A max. |
| Charging mode – BATTERY port output | 24 V / 40–60 V, 12 A max., 600 W max. |
| Battery maintenance mode – BATTERY port input | 40–60 V, 3 A max. |
| Battery maintenance mode – ALT IN output | 13.8 V / 27.6 V, 100 W max. |
| Regenerative charging mode – BATTERY port input | 40-60 V, 12 A max. |
| Regenerative charging mode – ALT IN output | 13.8 V / 27.6 V, 45 A max. |
| Fuse rating | 125 A |
| Protections | Reverse polarity protection, overcurrent protection, short-circuit protection, overvoltage and undervoltage protection, over-discharge protection for the storage battery (built-in overload protection) |
| Ingress protection rating | IP4X |
| Operating temperature | -10°C to 45°C |
| Storage temperature | From -30°C to 70°C |
| Operating humidity | ≤95% |
| Storage humidity | ≤95% |
Which vehicle battery chemistries are compatible?
The charger works with 12V and 24V vehicle electrical systems and supports AGM, lead-acid, and LiFePO4 starter batteries.
What items are included in the package?
The package contains the EcoFlow Alternator Charger 600W, an alternator input cable with integrated ignition wire (8 AWG, 5 m), an XT60 output cable (14 AWG, 1 m), a cable with 125 A fuse (8 AWG, 0.2 m), mounting screws and nuts, a user manual, and a warranty card.
How quickly can the charger replenish 1 kWh of power?
Operating at up to 600 W, the charger can recover approximately 1 kWh of energy in about 1.9 hours.
