DeWalt DWE7485-QS table saw, 210 mm, 1850 W

Price: 665.30 €

Products ID:	196870
Manufactured by:	Dewalt
Availablity:	Ready to Order
Delivery Time	7-15 business days
EAN:	5035048723371

Delivery options to:

Choose country

The DeWalt DWE7485-QS is a compact table saw with a 210 mm blade and an 1850 W motor. Its double-sided rack-guided rip fence supports precise positioning for longitudinal cuts, with an eccentric lever to lock the setting.

Cutting capacity and adjustment

Cutting depth is 65 mm at 90° and 45 mm at 45°. Rip capacity is 622.3 mm to the right of the blade and 318 mm to the left. Large controls make cutting depth and tilt easier to adjust, and a mitre cutting function is also provided.

Construction and workspace

Dust extraction: the system is compatible with AirLock.
Saw table: a 485 × 485 mm surface with a special coating.
Housing: fibreglass-reinforced construction with a protective frame.
Controls: a large emergency switch.

The saw operates from a 230 V mains supply. Its compact design makes it convenient to move between work locations.

Voltage	230 V
Nominal input power	1850 W
No-load speed	5800 rpm
Saw blade diameter	210 mm
Saw blade bore	30 mm
Blade kerf	1.8 mm
Blade body thickness	1.3 mm
Riving knife thickness	1.6 mm
Cutting depth at 90°	65 mm
Cutting depth at 45°	45 mm
Rip capacity to the right of the blade	622.3 mm
Rip capacity to the left of the blade	318 mm
Sound pressure level	90 dB(A)
Sound power level	107 dB(A)
Colour	Yellow / silver
Power supply	Mains
Type	Circular table saw
Mitre cutting function	Yes
Tilt function	Yes
Table size	485 × 485 mm
Rip fence	Double-sided rack guidance with eccentric locking lever
Dust extraction	AirLock-compatible
Construction	Fibreglass-reinforced housing, protective frame and specially coated table
Adjustment controls	Large cutting depth and tilt controls
Emergency switch	Large
