Newell BP-4CH 4-channel charger for V-mount batteries

228.20 € 242.20 € You save 14.00 € incl. VAT
In supplier warehouse · 7 pcs. Delivery Time: 7–15 business days

In your cart: 0

Delivery options to:

Choose country

The Newell BP-4CH is a 4-channel charger for V-mount, also known as V-Lock, batteries used in film and photography equipment. It can charge up to 4 batteries simultaneously and supply external equipment from installed batteries through its DC output.

Charging and equipment power

When charging 1–2 batteries simultaneously, the charging output is 16.8 V at 3 A per channel; with 3–4 batteries, it is 16.8 V at 2 A per channel. The charger accepts a 100–240 V mains supply. Its DC output provides 16.5 V at 4.5 A, with an included 4-pin XLR cable for connecting equipment with a suitable connection.

Monitoring and handling

  • LED indicators: green indicates a fully charged battery, while yellow indicates 85% charge. Indicators are also provided for battery discharge and powering external equipment.
  • Protection: systems protect batteries against overcharging and overheating.
  • Stable placement: folding feet and rubber pads support positioning.
  • Transport: a built-in handle makes the charger easier to carry.

The package includes the charger, a 150 cm power cable and a 300 cm XLR cable.


ModelNewell BP-4CH for V-mount batteries
Input100–240 V, 50/60 Hz, max. 3 A
DC output16.5 V, 4.5 A
Charging 1–2 batteries simultaneously16.8 V, 3 A × 1–2
Charging 3–4 batteries simultaneously16.8 V, 2 A × 3–4
Recommended ambient temperature0–40 °C
Recommended ambient humidity20–90 % RH
Power cable length150 cm
XLR cable length300 cm
ColourBlack
Dimensions265 × 103 × 223 mm
Weight3300 g
CompatibilityV-Mount (V-Lock) batteries
EAN5907489643894
Can it charge 4 batteries at once?

Yes, it has 4 V-mount slots. When charging 3–4 batteries simultaneously, the charging output is 16.8 V at 2 A per channel; for 1–2 batteries, it is 16.8 V at 3 A per channel.

Can it power a camera?

Yes. Installed V-mount batteries can supply compatible equipment through the DC output using the included 4-pin XLR cable. The output is rated at 16.5 V and 4.5 A.
