10" Color Indoor Monitor VTH5241DW-S2
Price: 278.20 €
| Products ID: | 172355 |
|---|---|
| Manufactured by: | Dahua Technology Co., Ltd |
| Availablity: | Ready to Order |
| Delivery Time | 5-10 business days |
| EAN: | 6939554965845 |
Delivery options to:
Choose countryThe VTH5241DW-S2 is a 10-inch color indoor monitor featuring a capacitive touch screen, network connectivity, and alarm integration for intercom systems.
Key Features
- 10" TFT capacitive touch screen with 1024x600 resolution
- Dual-way bidirectional talk with built-in microphone and loudspeaker
- Network connectivity via Wi-Fi (IEEE802.11b/g) and Ethernet
- Power supply via DC 12V or PoE (802.3af)
- 8 alarm inputs and 1 alarm output for system integration
- Micro SD card slot supporting up to 32GB
- Surface mounting installation
| Model | VTH5241DW-S2 |
|---|---|
| Display | 10" TFT Capacitive touch screen |
| Resolution | 1024x600 |
| Operating System | Embedded LINUX OS |
| Processor | Embedded Micro Processor |
| Video Compression | H.264 |
| Audio Compression | G.711 |
| Audio Input | All-direction Microphone |
| Audio Output | Built-in Loudspeaker |
| Bidirectional Talk | Dual-way supported |
| Wi-Fi | IEEE802.11b/g |
| Ethernet | 10M/100Mbps Self-adaptive |
| Network Protocol | TCP/IP |
| Alarm Interfaces | 8 In / 1 Out |
| RS485 | 1 |
| Memory Slot | Micro SD, Max 32GB |
| Power | DC 12V, PoE (802.3af) |
| Power Consumption | Standby =1W, Work =8W |
| Working Temperature | -10°C~+55°C |
| Relative Humidity | 10%~90%RH |
| Installation | Surface |
| Dimensions | 265.0mm×180.0mm×21.0mm |
| Weight | 1.0Kg |
Does the monitor support PoE power supply?
Yes, the monitor supports power via PoE (802.3af) as well as standard DC 12V.
What is the maximum capacity for the Micro SD card?
The monitor supports optional Micro SD cards with a capacity of up to 32GB for recording and snapshots.
How does the monitor connect to the network?
It connects via Wi-Fi (IEEE802.11b/g) or a wired 10/100Mbps self-adaptive Ethernet port.
