Anycubic Photon Mono 4 Ultra 10K resin 3D printer
Delivery options to:
Choose countryThe Anycubic Photon Mono 4 Ultra is a resin 3D printer with a 7-inch 10K monochrome LCD and 17 × 17 μm XY resolution. Its 153.4 × 87 × 165 mm build volume accommodates detailed prototypes, jewellery models and artistic projects.
Light system and print settings
A COB light source, Fresnel lens and light uniformity algorithm provide light uniformity of at least 90%. The light source has a service life of up to 20 000 hours. Layer height can be set from 0.02 to 0.15 mm.
- Speed: at a 0.1 mm layer height, peak speed is 80 mm/h with standard resin or 120 mm/h with high-speed resin.
- Controls: a 4.3-inch TFT touchscreen and manual four-point platform levelling.
- Materials: supports most commercially available resins, including water-washable and plant-based types.
- Software: Photon Workshop slicing software, plus support for the Anycubic app and smart printing system.
Equipment and footprint
The package includes a print bed, resin tank, screen protection kit, levelling paper and other preparation accessories. The printer measures 231 × 236 × 430 mm and weighs 5 kg.
| Manufacturer | Anycubic |
|---|---|
| Build volume | 153.4 × 87 × 165 mm |
| Printer dimensions | 231 × 236 × 430 mm |
| Print speed | Standard resin at 0.1 mm layer height: 80 mm/h peak; high-speed resin at 0.1 mm layer height: 120 mm/h peak |
| Platform levelling | 4-point manual levelling |
| LCD screen | 7-inch monochrome 10K LCD |
| Light source | COB light source + Fresnel lens + light uniformity algorithm |
| XY resolution | 17 × 17 μm |
| Control screen | 4.3-inch TFT touchscreen |
| Slicing software | Photon Workshop |
| Compatible materials | Most commercially available resins: water-washable, standard, bio-resins, plant-based and others |
| File transfer | USB, Wi-Fi, LAN mode (Q4) |
| Printer weight | 5 kg |
| Light uniformity | ≥90% |
| Release film | ACF |
| Irradiance | ≥3 500 μW/cm² |
| Layer height | 0.02–0.15 mm |
| Package dimensions | 512 × 300 × 305 mm |
| Air purifier connection | USB |
| Anycubic app | Supported |
| Smart printing system | Supported |
| Light source service life | Up to 20 000 hours |
| EAN | 6974662351043 |
|---|
What is included in the package?
Photon Mono 4 Ultra printer, print bed, resin tank, user manual, screen protection kit, levelling paper, gloves, funnels, scrapers, hex key set, USB drive and power cord.
Does the printer have automatic levelling?
No. The platform uses manual four-point levelling.
