Smart Relay Shelly 1PM Mini Gen4, 2-Pack, Zigbee / Matter / Wi-Fi, Red
-9%
Price: 44.10 €40.00 €
| Products ID: | 147535 |
|---|---|
| Manufactured by: | Shelly |
| Availablity: | Ready to Order |
| Delivery Time | 5-12 business days |
| EAN: | 3800238070816 |
Delivery options to:
Choose countryThe Shelly 1PM Mini Gen4 controller enables remote electrical device control and precise power consumption measurement. Supporting Wi-Fi, Zigbee, Bluetooth, and Matter, it easily integrates into diverse home automation platforms. Its compact form factor fits into standard wall boxes behind switches or sockets. This set contains two controllers.
Key Features
- Simultaneous remote switching and power measurement
- Multi-protocol support: Wi-Fi, Zigbee, Bluetooth, and Matter
- Built-in web interface with MQTT, HTTPS, and Webhooks support
- Advanced scheduling with up to 20 schedules and Shelly Script support
- Integrated protections against overheating, overpower, overcurrent, and overvoltage
| Manufacturer | Shelly |
|---|---|
| Model | 1PMMiniGen4 |
| Dimensions | 29 x 34 x 16 ± 0.5 mm / 1.34 × 1.11 × 0.63 ±0.02 inches |
| Weight | 18 ±1 g / 0.63 ±0.04 oz |
| Maximum tightening torque for screw terminals | 0.4 Nm / 3.5 lbf.in |
| Wire cross-section | 0.2 to 2.5 mm² / 24 to 14 AWG (wire, stranded wire, and ferrules) |
| Wire stripping length | 6 to 7 mm / 0.24 to 0.28 inches |
| Mounting | Wall box |
| Housing material | Plastic |
| Housing color | Red |
| Connector color | Gray |
| Operating temperature | -20°C to 40°C / -5°F to 105°F |
| Operating humidity | 30% to 70% RH |
| Maximum altitude | 2000 m / 6562 ft |
| Power Supply | 110–240 V AC |
| Relay | NO contact, 1-pole, µ contact |
| External Protection | Triggering characteristic B or C, max. rated current 10 A, min. breaking capacity 6 kA, energy limitation class 3 |
| Maximum switching voltage | 240 V AC |
| Maximum switching current | 8 A / 240 V AC |
| Power measurement | Yes |
| Overvoltage protection / cut-off | Yes |
| Overload protection / cut-off | Yes |
| Power overload protection / cut-off | Yes |
| Built-in internal temperature sensor | Yes |
| Wi-Fi Protocol | 802.11 b/g/n |
| Wi-Fi RF band | 2412 – 2472 MHz |
| Wi-Fi Maximum RF power | < 20 dBm |
| Wi-Fi Range | Up to 30 m / 100 ft indoors and 50 m / 160 ft outdoors (depending on local conditions) |
| Bluetooth Protocol | 5.0 |
| Bluetooth RF Band | 2402 – 2480 MHz |
| Bluetooth Maximum RF Power | < 4 dBm |
| Bluetooth Range | Up to 10 m / 33 ft indoors and 30 m / 100 ft outdoors (depending on local conditions) |
| Zigbee Protocol | 802.15.4 |
| Zigbee RF bands | 2400 – 2483.5 MHz |
| Zigbee Maximum RF power | < 20 dBm |
| Zigbee Range | Up to 100 m / 328 ft indoors and 300 m / 984 ft outdoors (depending on local conditions) |
| CPU | ESP-Shelly-C68F |
| Flash memory | 8 MB |
| Schedules | 20 |
| Webhooks (URL actions) | 20, each with up to 5 URLs |
| Scripts | Yes |
| MQTT | Yes |
What is included in the package?
The package includes 2 Shelly controllers and a user manual.
What is the maximum switching current of the relay?
The maximum switching current is 8 A at 240 V AC.
Which wireless protocols are supported?
The device supports Wi-Fi, Zigbee, Bluetooth, and Matter protocols.
