Shelly Pro LoRa Add-on x1 Relay Module
Price: 73.60 €
| Products ID: | 159925 |
|---|---|
| Manufactured by: | Shelly |
| Availablity: | Ready to Order |
| Delivery Time | 5-10 business days |
| EAN: | 3800238073169 |
Delivery options to:
Choose countryThe Shelly Pro LoRa Add-on is a galvanically isolated expansion module designed for compatible devices from the Shelly Pro series. It enables energy-efficient wireless communication via LoRa technology over distances of up to 5 km, making it suitable for industrial facilities, agricultural applications, and large commercial buildings with limited standard network coverage.
Key Features
- Long-Range Connectivity: Data transmission over distances up to 5 km.
- Antenna Support: Equipped with an SMA connector and includes a compatible antenna.
- Secure Communication: Built-in AES-CCM encryption protects transmitted data.
- Simple Integration: Mounts on a DIN rail and draws power directly from a connected Shelly Pro device.
- Low Power Consumption: Consumes less than 150 mW.
| Manufacturer | Shelly |
|---|---|
| Model | LoRa Add-on x1 |
| Dimensions (with antenna) | 94 × 19 × 92 mm |
| Weight (with antenna) | 52 g |
| Mounting | DIN rail |
| Housing material | Plastic |
| Color | Black |
| Operating temperature | From -20°C to 40°C |
| Power supply | 3.3 V (from compatible Shelly device) |
| Power consumption | < 150 mW |
| LoRa frequency band | EU868 |
| Maximum range | Up to 5000 m |
Can the Shelly Pro LoRa Add-on work independently?
No, it is an expansion module that must be connected to a compatible Shelly Pro device for power and communication.
Does the module include an antenna?
Yes, the module comes with a compatible antenna featuring an SMA-M connector.
