Shelly Pro Dimmer 1 1-Channel DIN Rail Smart Dimmer

Q: What types of lighting loads are supported by the Shelly Pro Dimmer 1?

It supports loads up to 200 W, including LED bulbs, traditional incandescent bulbs, halogen bulbs, and low-voltage bulbs via transformers.

Q: Does the dimmer require a dedicated hub to operate?

No additional hub is required. The device can be operated locally or remotely using the Shelly Smart Control app, integrated web interface, or third-party platforms.

-8%

Shelly Pro Dimmer 1 1-Channel DIN Rail Smart Dimmer — primary image

Shelly Pro Dimmer 1 1-Channel DIN Rail Smart Dimmer — image 2

Shelly Pro Dimmer 1 1-Channel DIN Rail Smart Dimmer — image 3

Price: 76.50 €70.30 €

Products ID:	112690
Manufactured by:	Shelly
Availablity:	Ready to Order
Delivery Time	5-12 business days
EAN:	3800235268162

Delivery options to:

Choose country

Shelly Pro Dimmer 1 1-Channel DIN Rail Smart Dimmer

The Shelly Pro Dimmer 1 is a single-channel DIN-rail-mounted smart dimmer designed for lighting control in residential and commercial settings. It functions autonomously on a local Wi-Fi network or connects to cloud-based home automation platforms without requiring an external hub.

Key Features

Automatic dimming calibration for smooth brightness regulation
Flexible connectivity via Wi-Fi, Ethernet, and Bluetooth
Supports weekly schedules, timers, custom scenarios, and night mode
Compatible with Amazon Alexa, Google Home, and Samsung SmartThings
Protection against overheating, surges, overloads, and excessive power consumption
Operates with lighting loads up to 200 W, including LED, incandescent, and halogen bulbs

Manufacturer	Shelly
Model	ProDimmer1
Power supply	110-240 V ~50/60 Hz
Power consumption	< 2 W
Max. output power	200 W
Wi-Fi connectivity	802.11 b/g/n
Wi-Fi RF bandwidth	2401-2483 MHz
Max Wi-Fi RF power	< 20 dBm
Wi-Fi range	Up to 30 m indoors / up to 50 m outdoors
Bluetooth version	4.2
Bluetooth RF band	2400-2483.5 MHz
Max Bluetooth RF power	< 4 dBm
Bluetooth range	Up to 10 m indoors / up to 30 m outdoors
CPU	ESP32-D0WDQ6
Flash memory	8 MB
Max. number of schedules	20
Operating temperature	From -20°C to 40°C
Operating ambient humidity	From 30% to 70% RH
Material	Plastic
Dimensions	94 x 19 x 69 mm
Weight	75 g
Mounting	DIN rail
Compatibility	Amazon Alexa, Google Home, Samsung SmartThings

What types of lighting loads are supported by the Shelly Pro Dimmer 1?

It supports loads up to 200 W, including LED bulbs, traditional incandescent bulbs, halogen bulbs, and low-voltage bulbs via transformers.

Does the dimmer require a dedicated hub to operate?

No additional hub is required. The device can be operated locally or remotely using the Shelly Smart Control app, integrated web interface, or third-party platforms.
