Set of 2 Shelly 1 Gen4 Zigbee/Matter Controllers
-5%
Price: 45.90 €43.70 €
| Products ID: | 147538 |
|---|---|
| Manufactured by: | Shelly |
| Availablity: | Ready to Order |
| Delivery Time | 5-12 business days |
| EAN: | 3800238070694 |
Delivery options to:
Choose countryThe Shelly 1 Gen4 Zigbee/Matter is a compact flush-mounted smart controller with potential-free contacts designed for remote control of electrical devices via a local network and the internet. This set of two controllers is suitable for residential, office, and hotel installations.
Key Features
- Set includes 2 Shelly controllers and a user manual
- Supports Wi-Fi, Bluetooth 4.2, Zigbee, and Matter wireless protocols
- Functions as a Zigbee repeater and Wi-Fi signal booster
- Built-in web interface for convenient setup without extra apps
- Compatible with Google Home, Alexa, SmartThings, and KNX net/IP
- Supports up to 20 schedules, webhooks, and ShellyScript custom scripting
| Manufacturer | Shelly |
|---|---|
| Model | 1Gen4 |
| Dimensions | 37 x 42 x 16 mm / 1.46 x 1.65 x 0.63 inches |
| Weight | 26 g / 0.92 oz |
| Maximum tightening torque for screw terminals | 0.4 Nm / 3.5 lbin |
| Wire cross-section | 0.2 to 2.5 mm² / 24 to 14 AWG (solid, stranded, and sleeved wires) |
| Stripped wire length | 6 to 7 mm / 0.24 to 0.28 inches |
| Mounting | Wall mount |
| Housing material | Plastic |
| Housing color | Blue |
| Terminal color | Gray |
| Operating temperature | -20°C to 40°C / -5°F to 105°F |
| Operating humidity | 30% to 70% RH |
| Maximum altitude | 2000 m / 6562 ft |
| Power supply | 110–240 V~ ; 24–48 V= ; 12 V= |
| Power consumption | < 1 W |
| Neutral wire required | No |
| External protection | Overcurrent circuit breaker compliant with EN60898-1 (tripping characteristic B or C, rated current max. 16 A, minimum breaking capacity 6 kA, energy limitation class 3) |
| Maximum switching voltage | 240 V~ ; 30 V= |
| Maximum switching current | 16 A / 240 V~ ; 10 A / 30 V= |
| Built-in temperature sensor | Yes |
| Wi-Fi protocol | 802.11 b/g/n |
| Wi-Fi RF band | 2412 – 2472 MHz |
| Wi-Fi maximum RF transmit power | < 20 dBm |
| Wi-Fi range | Up to 30 m indoors / 100 feet and up to 50 m outdoors / 160 feet (depending on local conditions) |
| Bluetooth protocol | 4.2 |
| Bluetooth RF band | 2402 – 2480 MHz |
| Bluetooth maximum RF transmit power | < 4 dBm |
| Bluetooth range | Up to 10 m indoors / 33 feet and up to 30 m outdoors / 100 feet (depending on local conditions) |
| Zigbee protocol | 802.15.4 |
| Zigbee repeater function | Yes |
| Zigbee RF band | 2400 – 2483.5 MHz |
| Zigbee maximum RF transmit power | < 20 dBm |
| Zigbee range | Up to 100 m indoors / 328 ft and up to 300 m outdoors / 984 ft (depending on local conditions) |
| Processor | ESP-Shelly-C68F |
| Flash memory | 8 MB |
| Number of schedules | 20 |
| Webhooks (URL actions) | 20, with 5 URLs per webhook |
| Script support | Yes |
| MQTT | Yes |
What is included in the package?
The package contains two Shelly 1 Gen4 controllers and a user manual.
Is a neutral wire required for operation?
No, a neutral wire is not required according to the manufacturer specifications.
Which wireless protocols does the controller support?
The Shelly 1 Gen4 supports Wi-Fi (802.11 b/g/n), Bluetooth 4.2, Zigbee (802.15.4), and Matter.
