DIN Rail 3-Channel Relay Shelly Pro 3, WiFi / LAN
-23%
107.80 €82.80 €
Products ID: 101661
In supplier warehouse
Available to order: 7 pcs.
Delivery Time 5–12 business days
Delivery options to:
Choose countryShelly Pro 3 is an advanced DIN rail relay equipped with three independent channels for residential and commercial building automation.
Key Features
- Three independent channels supporting up to 16 A each (48 A total)
- Connectivity via WiFi, LAN, and Bluetooth
- Potential-free contacts for versatile voltage switching
- Scripting capability to create custom event-driven automation scenes
- Compatible with Google Assistant, Samsung SmartThings, and Amazon Alexa
| Manufacturer | Shelly |
|---|---|
| Model | SPSW-003XE16EU |
| AC Power Supply Voltage | 110 - 240 V |
| Power Consumption | < 3 W |
| Max AC Switching Voltage | 240 V |
| Max DC Switching Voltage | 30 V |
| Max AC Switching Current | 16 A per channel, 48 A total |
| Max DC Switching Current | 16 A per channel, 48 A total |
| Internal Temperature Sensor | Yes |
| Wi-Fi Protocol | 802.11 b/g/n |
| Wi-Fi Range | Up to 30 m indoors and up to 50 m outdoors |
| Bluetooth Protocol | 4.2 |
| Bluetooth Range | Up to 10 m indoors and up to 30 m outdoors |
| CPU | ESP32-D0WDQ6 |
| Flash Memory | 8 MB |
| Dimensions | 96 x 53 x 59 ±0.5 mm |
| Mounting | DIN Rail |
| Housing Material | Plastic |
| Ambient Operating Temperature | From -20°C to +40°C |
| Humidity | From 30% to 70% RH |
| Maximum Altitude | 2000 m |
| EAN | 3800235268094 |
|---|
What is the maximum current rating per channel for Shelly Pro 3?
Each independent channel supports up to 16 A, with a total device capacity of up to 48 A.
What network connectivity options does the relay support?
It supports 2.4 GHz WiFi (802.11 b/g/n), wired LAN, and Bluetooth 4.2.
How is the Shelly Pro 3 installed?
It is designed to be mounted directly onto a standard DIN rail.
