Doweling Jig for Woodworking NZ12, Dark Blue
| Products ID: | 121569 |
|---|---|
| Availablity: | SOLDOUT! |
| EAN: | 5907621823313 |
Delivery options to:
Choose country
A practical tool designed for creating precise dowel joints in woodworking and furniture assembly. This jig ensures accurate alignment and stable drilling for professional results.
Practical Application
This tool is ideal for DIY enthusiasts and carpenters who need to drill holes in wooden boards with high precision. The movable pin and integrated clamp allow for easy adjustment to different board thicknesses, keeping the tool securely in place during use.
Key Features
- Versatile Joints: Supports the creation of E, L, and T type dowel connections.
- Precision Alignment: Movable pin allows for accurate hole tracing in wooden panels.
- Stable Grip: Comfortable clamp ensures the tool stays fixed while drilling.
- Multi-Size Support: Designed for 6mm, 8mm, and 10mm diameter dowels.
- Board Compatibility: Suitable for wooden boards with a thickness ranging from 12mm to 30mm.
Technical Specifications
| Brand | Generic |
| Model | NZ12 |
| Material | ABS Plastic + Metal |
| Dimensions | 20 cm x 7.5 cm x 4 cm |
| Color | Dark Blue |
Frequently Asked Questions
What types of joints can I make with this jig?
This tool is specifically designed for E, L, and T-shaped dowel connections, covering most furniture assembly needs.
What drill bit sizes are compatible?
The jig features guides for 6mm, 8mm, and 10mm drill bits and dowels.
What is the maximum board thickness it can handle?
The tool is adjustable and works with boards ranging from 12mm up to 30mm in thickness.
Is the tool durable for frequent use?
Yes, it is made from high-quality ABS plastic with metal components in the drilling guides for increased wear resistance.
