SkyRC D100neo Dual-Port AC/DC Battery Charger

SkyRC D100neo Dual-Port AC/DC Battery Charger — image 3

Price: 76.70 €

Products ID:	174480
Manufactured by:	Skyrc
Availablity:	Ready to Order
Delivery Time	5-10 business days
EAN:	6930460008084

Delivery options to:

Choose country

SkyRC D100neo Dual-Port AC/DC Battery Charger

The SkyRC D100neo is a compact dual-channel smart battery charger capable of operating on AC and DC power supplies for versatile battery maintenance.

Key Features

Dual-port charging with up to 100W on AC and up to 200W on DC power
Compatible with LiPo, LiHV, LiFe, Li-ion (1-6S), NiMH, NiCd (1-15S), and Pb batteries
Charge current adjustable from 0.2A to 10.0A per port with ±0.02V balancing accuracy
2.8-inch color TN display with 240x320 resolution and ColorX interface
USB-C port supporting 20W Power Delivery and QC3.0 fast charging
PC and Mac connectivity via USB-C for parameters control and updates with Charger Master

Brand	SkyRC
Model	SK-100199-01
Case Material	PC-ABS V0
Dimensions	116 x 110 x 79 mm
Weight	470 g
Display	2.8" TN, 240x320 px, 262,000 colors
AC Input Voltage	100-240V
DC Input Voltage	10-30V
Charger Power	AC: 100W MAX; DC: 200W MAX
Discharge Power	Main Port: 5W; Balance Port: 25W MAX (LiPo/6S)
Charge Current	0.2-10.0A
Discharge Current	0.1-2.0A
Balance Current	1.0A MAX
Balancing Accuracy	±0.02V
Battery Types/Cells	LiPo/LiHV/LiFe/LiIon: 1-6 cells; NiMH/NiCd: 1-15 cells; Pb: 3S/6S/12S
USB-C PD Output	PD: 5V⎓3A, 9V⎓2.2A, 12V⎓1.67A 20W; QC3.0: 5V⎓3A, 9V⎓2A, 12V⎓1.5A 18W

What is the charging power difference between AC and DC inputs?

When powered by AC mains (100-240V), total power is dynamically distributed up to 100W. When connected to a DC source (10-30V), power reaches up to 200W.

Which battery types can be charged with the SkyRC D100neo?

It supports 1-6S LiPo, LiHV, LiFe, and Li-ion, 1-15S NiMH and NiCd, as well as 3S, 6S, and 12S Pb (lead-acid) batteries.

What functions does the USB-C port provide?

The USB-C port offers 20W Power Delivery and QC3.0 output for devices, as well as data connection to PC/Mac for firmware updates and Charger Master software control.
