Electronic Irrigation Valve RainPoint BIV025ESC-DC 1" DC Latch IP68
Rainpoint-23%
Price: 26.10 €20.10 €
| Products ID: | 148007 |
|---|---|
| Manufactured by: | Rainpoint |
| Availablity: | Ready to Order |
| Delivery Time | 5-12 business days |
| EAN: | 5905156102774 |
Delivery options to:
Choose countryThe RainPoint BIV025ESC-DC electronic solenoid valve with 1" thread is designed for automated water flow control in garden irrigation systems.
Key Features
- Operates at 9–24 V DC using a DC Latch pulse coil for low energy consumption.
- Standard 1" BSP connections provide compatibility with irrigation controllers and fittings.
- Supports an operating pressure range of 0.2–10 bar and operating temperatures up to 60°C.
- Sealed construction with IP68 ingress protection for operation in wet outdoor environments.
| Manufacturer | RainPoint |
|---|---|
| Model | BIV025ESC-DC |
| Connection diameter | 1” |
| Operating voltage | 9–24 V DC (Latch) |
| Control type | Pulse (DC Latch) |
| Pulse duration | ≥200 ms |
| Minimum capacitance | 4700 µF |
| Operating pressure | 0.2–10 bar |
| Operating temperature | up to 60°C |
| Protection rating | IP68 |
What connection thread does this valve use?
The valve uses standard 1" BSP threaded connections.
What power supply is required to trigger the valve?
It operates on 9–24 V DC latch pulse control with a pulse duration of 200 ms or greater.
What is the supported operating pressure range?
The valve operates within a pressure range of 0.2 to 10 bar.
