Wolfcraft Drill Stand 5029000, Ø 43 mm
Price: 125.80 €
| Products ID: | 181241 |
|---|---|
| Manufactured by: | Wolfcraft |
| Availablity: | Ready to Order |
| Delivery Time | 7-15 business days |
| EAN: | 4006885502901 |
Delivery options to:
Choose country
The Wolfcraft drill stand enables precise and controlled drilling with standard drills fitted with a Euronorm collar.
Key Features
- Euronorm holder Ø 43 mm compatible with standard drills
- 40 mm round column with a 420 mm long toothed bar for straight drilling without twisting
- Depth stop with quick adjustment and scale ring for millimetre precision
- Rack and pinion drive for stepless, precise height adjustment
- Stable grey cast iron base plate for a secure stand
- 3-arm feed lever and return spring for easy machine lowering and return
- Clamping grooves in the base plate to mount vices
- Cable holder for orderly routing of the drill power cable
| Type | Drill Stand |
|---|---|
| Collar diameter | Euronorm Ø 43 mm |
| Column diameter | 40 mm |
| Toothed bar length | 420 mm |
| Working height | 305 mm |
| Projection | 130 mm |
| Material | Die-cast aluminium |
| Base plate material | Grey cast iron |
| Dimensions (W x D x H) | 203 x 307 x 570 mm |
| Weight | 8 092 g |
| Number of parts | 1 |
| Field of application | Universal |
Which drills fit this drill stand?
The stand features a standard Euronorm holder with a 43 mm diameter collar compatible with common drills.
What are the working height and projection of this stand?
The working height is 305 mm and the projection is 130 mm.
