Hypershell Charging Hub for 4 Batteries
Hypershell
| Products ID: | 187228 |
|---|---|
| Manufactured by: | Hypershell |
| Availablity: | Ready to Order |
| Delivery Time | 5-12 business days |
| EAN: | 6977518000034 |
Delivery options to:
Choose country
The Hypershell Charging Hub connects and charges up to four batteries, optimizing power management for Hypershell exoskeleton operation. With a lightweight 70 g design and compact proportions, it fits effortlessly into a backpack or gear bag.
Intelligent Sequential Charging
The hub automatically detects and prioritizes the battery with the highest remaining charge level, bringing it to full capacity before switching to the next battery. This sequential process reduces equipment downtime during outdoor expeditions and field use.
Integrated LED Indicators
Built-in LEDs provide instant status feedback without connecting external devices. Distinct colors and lighting modes indicate standby readiness, active charging progress, and completed full charge.
USB-C Power Delivery Compatibility
Designed for USB-C PD chargers up to 65 W, the hub supports 5 V, 9 V, and 12 V power inputs. Charging a single battery takes approximately 90 minutes when paired with a compatible 65 W charger.
| Manufacturer | Hypershell |
|---|---|
| Model | HSHUB |
| Input | 5–20 V AC, 65 W, 3250 mA |
| Output | Max. 16.8 V DC |
| Number of ports | 4 |
| Charging port | USB-C port; PD (Power Delivery) protocol |
| Operating temperature | -20°C to 60°C |
| Charging temperature | 0°C to 40°C |
| Standard charging time | 90 min using the Hypershell 65 W charger (optional) for each battery |
| Compatibility | All Hypershell batteries |
| Supported chargers | Hypershell 65 W charger or other USB-C PD chargers (5 V, 9 V, 12 V) |
| Dimensions | 240 × 350 × 170 mm |
| Weight | 70 g |
How many batteries can the charging hub charge?
The hub features 4 dedicated ports to connect and sequentially charge up to 4 Hypershell batteries.
How long does it take to charge one battery?
Charging a single battery takes approximately 90 minutes when using the optional Hypershell 65 W charger.
How does the sequential charging system work?
The hub prioritizes the battery with the highest charge level, fully charges it first, and then automatically proceeds to the next.
